(No.YA442)3-3
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST -1
P.W.B ASS'Y AV-2186ME AV-21MS16/H AV-21MS26 AV-21MX16/G AV-21MX16/S AV-21MX56/S AV-21MX76/G
MAIN P.W.B
SCW-1901A-H2 SCW-1903A-H2 SCW-1902A-H2 SCW-1910A-H2 SCW-1912A-H2 SCW-1911A-H2 SCW-1908A-H2
BASS P.W.B
SCW-6001A-H2
←←←←←←
REMOTE CONTROL UNIT RM-C1285-1H RM-C1286-1H ←←←RM-C1285-1H ←
Ref.No. Part No. Part Name Description Local
V01 A51AKL13X25K/M/ PICTURE TUBE(ITC) Inc.DEF YOKE
AV-2186ME,AV-21MS16H,AV-21MS26,AV-21MX16G,AV-21MX16S,AV-21MX56S
V01 A51QGA993X CRT AV-21MX76G
DY01 QQD0135-001 DEF YOKE AV-21MX76G
L01 QQW0210-001 DEG COIL
T522 QQH0188-001 FB TRANSF
1 GG10341-001B-H SP PANEL (x2)
2 GG30117-001A-H OPERATION SHEET
11 QYSBSBG4016ZA TAP SCREW M4 x 16mm(x2)
12 QYSBSFG4016ZA TAP SCREW M4 x 16mm(x7)
13 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
14 GG10187-218A-H REAR COVER
15 CM47005-A01-H POWER CORD CLAMP
16 QMPR340-165-K2 POWER CORD 1.65m BLACK AV-2186ME,AV-21MS26,AV-21MX16G,AV-21MX76G
16 QMPR650-165-JC POWER CORD 1.65m BLACK AV-21MS16H,AV-21MX16S,AV-21MX56S
17 CM48144-004-H PB STOPPER
AV-21MS16H,AV-21MS26,AV-21MX16G,AV-21MX16S,AV-21MX56S,AV-21MX76G
18 GG30119-001B-H SUB PCB HOLDER
19 QAL0608-001 PC MAGNET
20 QAL0627-001 DY WEDGE (x3)
21 A48457-3-H SPRING
22 WJY0029-001A-E BRAIDED ASS'Y
23 WJY0013-003A-E BRAIDED ASS'Y
24 CM36623-003-H CHASSIS RAIL (x2)
25 GG40046-001A-H TAP SCREW (x4)
26 LC40226-005A-H SPACER (x4)
27 GG20057-002A-H SPEAKER HOLDER (x4)
28 QAS0348-001 SPEAKER (x2) SP01,SP02
30 SCW-1901A-H2 MAIN PWB AV-2186ME
30 SCW-1903A-H2 MAIN PWB AV-21MS16H
30 SCW-1902A-H2 MAIN PWB AV-21MS26
30 SCW-1910A-H2 MAIN PWB AV-21MX16G
30 SCW-1912A-H2 MAIN PWB AV-21MX16S
30 SCW-1911A-H2 MAIN PWB AV-21MX56S
30 SCW-1908A-H2 MAIN PWB AV-21MX76G
31 SCW-6001A-H2 BASS PWB
100 GG10338-003B-H FRONT CABINET ASS'Y Inc.101-106
AV-2186ME,AV-21MS16H,AV-21MX16G,AV-21MX16S,AV-21MX56S
100 GG10338-003A-H FRONT CABINET ASS'Y Inc.101-106 AV-21MS26,AV-21MX76G
101 GG10340-001B-H FRONT FRAME TOP
102 GG10340-002B-H FRONT FRAME BOTTOM
103 GG20082-001B-H DOOR
104 GG30114-001B-H POWER KNOB
105 CM35235-003-H SPRING
106 GG30115-001B-H LED LENS
To Next Page
