3-14
Function board(KD-G227_EE)
Block No. [0][6]
Main board
(KD-G321,G322_E,EX,EY,EU)
Block No. [0][7]
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R630 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R631 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R633 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R634 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R635 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R637 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R639 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R641 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R643 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R645 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R649 NRS181J-391X MG RESISTOR 390
Ω
1/8W J
R650 NRS181J-391X MG RESISTOR 390
Ω
1/8W J
R661 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R662 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R663 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R664 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R665 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R666 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R667 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R668 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R670 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R671 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R672 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R681 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R682 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R686 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R687 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R688 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
IC501 LA6242H-X IC
Q501 2SA1705/ST/-T TRANSISTOR
C501 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C503 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C504 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31HK-222X C CAPACITOR 2200pF 50V K
Symbol No.
Part No. Part Name Description Local
C513 NCB31HK-682X C CAPACITOR 6800pF 50V K
C515 NCB31HK-122X C CAPACITOR 1200pF 50V K
C517 NCB31HK-182X C CAPACITOR 1800pF 50V K
C518 NDC31HJ-680X C CAPACITOR 68pF 50V J
R500 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R501 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R502 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R503 NRSA63J-512X MG RESISTOR 5.1k
Ω
1/16W J
R505 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
R506 NRSA63J-303X MG RESISTOR 30k
Ω
1/16W J
R507 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R508 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R509 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R510 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R511 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R512 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R513 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R514 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R515 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R516 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R517 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R518 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R519 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R520 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R568 NRSA63J-752X MG RESISTOR 7.5k
Ω
1/16W J
R569 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
CN502 QGZ2512M1-10 CONNECTOR (1-10)
CN503 QGZ2512M1-08 CONNECTOR (1-8)
Symbol No.
Part No. Part Name Description Local
IC71 LC72725NM-X IC
IC171 NJW1192V-X IC
IC301 LA47201 POWER AMP IC
IC521 MN6627945EE IC
IC523 SN74LVC2G07V-X LOGIC IC
IC581 NJM4565E-X IC
IC701 MN101C49KST IC
IC771 BR24L16F-W-X IC
IC775 S-80833CNNB-G-W IC
IC901 AN80T71 REGULATOR IC
IC981 NJU7772F15-X IC
Q74 RT1N141C-X DIGI TRANSISTOR
Q301 2SC3928A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q521 2SA1530A/QR/-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q782 RT1P141C-X DIGI TRANSISTOR
Q891 RT1N141C-X DIGI TRANSISTOR
Q911 2SA1530A/QR/-X TRANSISTOR
Q912 RT1N141C-X DIGI TRANSISTOR
D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D301 UDZS3.3B-X Z DIODE
D341 1SS355W-X DIODE C.M
D351 1SS355W-X DIODE C.M
D501 1A3G-T1 SI DIODE
D711 UDZW6.2B-X SI DIODE
D712 UDZW6.2B-X SI DIODE
D713 UDZW6.2B-X SI DIODE
D714 UDZW6.2B-X SI DIODE
D715 UDZW6.2B-X SI DIODE
D716 UDZW6.2B-X SI DIODE
D717 UDZW6.2B-X SI DIODE
Symbol No.
Part No. Part Name Description Local
