JVC KD-G312 User Manual

3-12
Main board
(KD-G311,KD-G312_E2,EX2,EY2,EU2)
Block No. [0][3]
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRS/ LED
D632 NSPW310BS/BRS/ LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
D644 MA8062/M/-X Z DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R606 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R611 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R612 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R627 NRSA02J-391X MG RESISTOR 390 Ω 1/10W J
R628 NRSA02J-391X MG RESISTOR 390 Ω 1/10W J
R629 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R630 NRSA63J-132X MG RESISTOR 1.3k Ω 1/16W J
R631 NRSA63J-132X MG RESISTOR 1.3k Ω 1/16W J
R632 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R634 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R636 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R638 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R640 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R642 NRSA63J-132X MG RESISTOR 1.3k Ω 1/16W J
R643 NRSA63J-132X MG RESISTOR 1.3k Ω 1/16W J
R644 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R653 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R658 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R662 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R671 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R672 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R673 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
S618 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC161 NJW1191V-X IC
IC171 NJM4565M-WE IC
IC301 LA47516 POWER IC
IC401 TC94A34FG-002 IC
IC461 NJU7772F15-X IC
IC481 AK4385ET-X IC
IC491 SN74AHCT1G04K-X IC
IC501 LA6242H-X IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC307 IC
IC702 IC-PST3433U-X IC
IC771 BR24L16F-W-X IC
IC901 HA13164A IC
Q1 2SD601A/QR/-X TRANSISTOR
Q2 2SD601A/QR/-X TRANSISTOR
Q3 UN2111-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q10 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q51 2SD601A/QR/-X TRANSISTOR
Q52 2SD601A/QR/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q81 2SD601A/QR/-X TRANSISTOR
Q84 UN2111-X TRANSISTOR
Q91 2SD601A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q440 UN2211-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB1132/QR/-W TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 UN2111-X TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q543 UN2111-X TRANSISTOR
Q544 2SB624/4/-X TRANSISTOR
Q545 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2213-X DIGI TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D4 MA111-X SI DIODE
D5 MA111-X SI DIODE
D84 MA111-X SI DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D481 MA8051/M/-X Z DIODE
D701 MA8062/M/-X Z DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
 Symbol No. Part No. Part Name Description Local
