3-10
Front board Block No. [0][2]
R550 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R551 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R552 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R553 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R558 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R559 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R581 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R582 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R583 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R584 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R585 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R586 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R587 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R588 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R591 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R592 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R593 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R594 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R595 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R596 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R597 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R598 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R701 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R702 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R703 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R704 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R705 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R707 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R714 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R715 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R716 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R717 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R718 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R720 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R722 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R725 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R726 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R728 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R730 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R732 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R734 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R735 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R742 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R743 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R744 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R746 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R747 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R748 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R749 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R752 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R753 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R754 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R755 NRSA63J-106X MG RESISTOR 10M
Ω
1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R757 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R762 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R763 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R766 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R767 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R771 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R793 NRS181J-0R0X MG RESISTOR 0
Ω
1/8W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R892 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
Symbol
No.
Part No. Part Name Description Local
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω
1/10W J
R977 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
R998 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
RA30 NRZ0065-222X NET RESISTOR 2.2k
Ω
RA550 NRZ0065-103X NET RESISTOR 10k
Ω
RA701 NRZ0065-102X MG RESISTOR 1k
Ω
L1 QQL244J-4R7Z COIL 4.7uH J
L401 NQL114K-470X INDUCITOR 47uH K
L402 NQL114K-470X INDUCITOR 47uH K
L404 NQL114K-470X INDUCITOR 47uH K
L541 QQL244J-470Z COIL 47uH J
L543 QQL244J-470Z COIL 47uH J
L544 QQL244J-470Z COIL 47uH J
L701 NQL114M-4R7X COIL 4.7uH M
L702 NQL114M-4R7X COIL 4.7uH M
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN702 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0650-001 CAR CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0519-001 PIN JACK
PP2 QZW0010-001 STYLE PIN
TU1 QAU0313-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X71 QAX0263-001Z CRYSTAL 4.332MHz
X401 QAX0760-001Z CRYSTAL
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol
No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
Q670 2SB624/4/-X TRANSISTOR
Q671 UN2211-X TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D632 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D634 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 NSPW310BS/BRS/ LED
D653 NSPW310BS/BRS/ LED
D661 MA111-X SI DIODE
D662 UDZS5.1B-X Z DIODE
Symbol
No.
Part No. Part Name Description Local
