3-6
Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC161 TEA6320T-X IC
IC301 LA47515 IC
IC401 TC94A34FG-002 IC
IC461 NJU7772F15-X IC
IC481 AK4385VT-X IC
IC501 LA6242H-X IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC238 IC
IC702 IC-PST3433U-X IC
IC771 BR24L16F-W-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
Q1 2SD601A/R/-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q10 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q401 2SB624/4/-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q430 2SD601A/QR/-X TRANSISTOR
Q440 UN2211-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB1132/QR/-W TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 UN2111-X TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q543 UN2111-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q881 UN2211-X TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D4 MA111-X SI DIODE
D5 MA111-X SI DIODE
D51 MA111-X SI DIODE
D240 MA111-X SI DIODE
D241 MA111-X SI DIODE
D242 MA111-X SI DIODE
D243 RB160M-30-X SB DIODE
D244 UDZS5.1B-X Z DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D361 UDZS11B-X Z DIODE
D701 MA8062/M/-X Z DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D713 MA111-X SI DIODE
D714 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D715 LNJ308G81/1-3/X LED
D716 LNJ308G81/1-3/X LED
D717 LNJ308G81/1-3/X LED
D718 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D784 UDZS11B-X Z DIODE
D901 1N5401-TU-15 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C11 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C49 NCB31HK-102X C CAPACITOR 1000pF 50V K
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J
C51 NDC31HJ-331X C CAPACITOR 330pF 50V J
C81 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C82 NCB31HK-152X C CAPACITOR 1500pF 50V K
C84 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C91 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C92 NCB31HK-152X C CAPACITOR 1500pF 50V K
C94 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C161 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C162 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C163 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C164 NCB31HK-822X C CAPACITOR 8200pF 50V K
C165 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C166 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C167 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C168 NCB31HK-562X C CAPACITOR 5600pF 50V K
C169 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C170 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C171 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C172 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C173 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C174 NCB31HK-822X C CAPACITOR 8200pF 50V K
C175 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C176 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C177 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C178 NCB31HK-562X C CAPACITOR 5600pF 50V K
C179 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C180 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C191 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C192 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C193 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C194 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C241 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C242 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C243 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C244 QEKJ1HM-224Z E CAPACITOR 0.22uF 50V M
C247 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C301 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C302 QFVD1HJ-474Z MF CAPACITOR 0.47uF 50V J
C303 NCS31HJ-391X C CAPACITOR 390pF 50V J
