(No.MA122)1-29
5.8
16 PIN CORD DIAGRAM (for KD-AR560
)
8
7
6
5
4
3
2
1
GY
VI
GN
WH
BL/WH
NC
RD
BK
16
15
14
13
12
11
10
9
YL
GY/BK
VI/BK
GN/BK
WH/BK
OR/WH
NC
BR
GND
CAUTION!
REMOTE
OUTPUT
ONL
Y
GND
16 YL
8 BK
7 RD
15 OR/WH
3 GN
1
1 GN/BK
2 VI
10 VI/BK
4 WH
12 WH/BK
1 GY
9 GY/BK
5 BL/WH
MEMORY
GND
ACC
ILL
RL+
RL-
RR+
RR-
FL+
FL-
FR+
FR-
REMOTE
13 BR
TEL
BK
RD
BL
WH
BR
Black
Red
Blue
White
Brown
GN
VI
GY
YL
OR
Green
Violet
Gray
Y
ellow
Orange
RR
FR
FL
RL
TEL
Rear Right
Front Right
Front Left
Rear Left
T
elephone muting
REMOTE
ACC
MEMORY
ILL
Remote out
ACC Line
Memory Backup Battery +
Ground
Illuminations Control
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
28
30
Table of Contents
Table of Contents
1
Specification
2
Safety Precautions
3
Preventing Static Electricity
4
Grounding to Prevent Damage by Static Electricity
4
Handling the Traverse Unit (Optical Pickup)
4
Attention When Traverse Unit Is Decomposed
4
Name Plate
5
Specific Service Instructions
5
Removing the Front Panel Assembly
6
Removing the Bottom Cover
6
Disassembly
6
Removing the Side Panel
7
Removing the Front Chassis Assembly
7
Removing the Rear Bracket
8
Removing the Main Board
8
Removing the CD Mecha Control Board
8
Removing the CD Mechanism Assembly
9
Removing the Switch Board
9
CD Mechanism Section
10
Removing the Top Cover
10
Removing the Connector Board
11
Removing the DET Switch
12
Removing the Chassis Unit
13
Removing the Clamper Assembly
14
Removing the Loading / Feed Motor Assembly
15
Reattaching the Pickup Unit
16
Removing the Pickup Unit
16
Removing the Trigger Arm
17
Removing the Top Plate Assembly
17
Removing the Mode Sw. / Select Lock Arm
18
Removing the Select Arm R / Link Plate
20
Reattaching the Select Arm R / Link Plate
20
Removing the Loading Roller Assembly
21
Removing the Gears
23
Pull out the Loading Gear
23
Removing the Turn Table / Spindle Motor
24
Adjustment Method
25
Test Instruments Required for Adjustment
25
How to Connect the Extension Cable for Adjusting
25
Spindle Section Troubles/Tracking Section Troubles
26
Feed Section Troubles
26
Focus Section Troubles
26
Troubleshooting
26
Signal Processing Section Troubles
27
Maintenance of Laser Pickup
28
Replacement of Laser Pickup
28
16 Pin Cord Diagram
29
Schematic Diagrams
33
Safety Precaution
34
Block Diagram
36
Standard Schematic Diagrams
38
Printed Circuit Boards
44
Exploded Views and Part Lists
61
Loading Gear
67
Packing Materials and Accessories Parts List
82
