JVC KD-G701 User Manual

3-8
Electrical parts list
Main board (KD-G701E,EX)
Block No. [0][1]

Symbol
No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC161 BD3807K IC
IC301 LA47515 IC
IC401 TC94A34FG-002 IC
IC461 NJU7772F15-X IC
IC481 AK4385ET-X IC
IC501 LA6242H-X IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC262 IC
IC702 IC-PST3433U-X IC
IC703 BR24L32F-W-X IC
IC901 HA13164A IC
IC951 BA6956AN IC
Q1 UN2211-X TRANSISTOR
Q2 2SD601A/R/-X TRANSISTOR
Q3 UN2111-X TRANSISTOR
Q4 2SB709A/R/-X TRANSISTOR
Q5 2SB624/4/-X TRANSISTOR
Q6 UN2211-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q51 2SD601A/R/-X TRANSISTOR
Q52 2SD601A/R/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q71 UN2111-X TRANSISTOR
Q73 2SD601A/R/-X TRANSISTOR
Q74 2SD601A/R/-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q321 2SD1781K/QR/-X TRANSISTOR
Q331 2SD1781K/QR/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q401 2SD601A/QR/-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q403 2SB624/4/-X TRANSISTOR
Q404 UN2211-X TRANSISTOR
Q481 UN2111-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB624/4/-X TRANSISTOR
Q503 UN2211-X TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q783 UN2111-X TRANSISTOR
Q841 UN2211-X TRANSISTOR
Q881 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q901 2SB709A/QR/-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
Q951 UN2211-X TRANSISTOR
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D3 1SS355-X SI DIODE
D4 1SS355-X SI DIODE
D71 1SS355-X SI DIODE
D161 1SS355-X SI DIODE
D162 1SS355-X SI DIODE
D241 CRS03-W SB DIODE
D242 1SS355-X SI DIODE
D243 UDZS5.1B-X Z DIODE
D321 1SS355-X SI DIODE
D331 1SS355-X SI DIODE
D341 1SS355-X SI DIODE
D351 1SS355-X SI DIODE
D481 UDZS5.1B-X Z DIODE
D501 1A3G-T1 SI DIODE
D701 UDZS6.2B-X Z DIODE
D702 1SS355-X SI DIODE
D704 UDZS6.2B-X Z DIODE
D705 UDZS6.2B-X Z DIODE
D706 UDZS6.2B-X Z DIODE
D717 UDZS6.2B-X Z DIODE
D718 1SS355-X SI DIODE
D719 1SS355-X SI DIODE
D781 1SS355-X SI DIODE
D782 1SS355-X SI DIODE
D783 UDZS11B-X Z DIODE
D891 1SS355-X SI DIODE
D892 1SS355-X SI DIODE
D901 1N5401-TU-15 DIODE
D902 CRS03-W SB DIODE
G701
E
D902 RB160M-30-X SB DIODE
G701
EX
D903 CRS03-W SB DIODE
D904 1SS355-X SI DIODE
D951 UDZS3.9B-X Z DIODE
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C8 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C10 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J
C51 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C52 NCB31EK-472X C CAPACITOR 4700pF 25V K
C53 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C54 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C55 NDC31HJ-331X C CAPACITOR 330pF 50V J
C71 NDC31HJ-820X C CAPACITOR 82pF 50V J
C72 NDC31HJ-470X C CAPACITOR 47pF 50V J
C73 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C74 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C75 NDC31HJ-561X C CAPACITOR 560pF 50V J
C76 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C77 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C78 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C79 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C81 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C82 NCB31HK-102X C CAPACITOR 1000pF 50V K
C83 NCB31HK-182X C CAPACITOR 1800pF 50V K
C84 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C91 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C92 NCB31HK-102X C CAPACITOR 1000pF 50V K
C93 NCB31HK-182X C CAPACITOR 1800pF 50V K
C94 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C161 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C162 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C163 QEKJ1HM-105Z E CAPACITOR 1uF 50V M

Symbol
No.
Part No. Part Name Description Local
