4
ENGLISH
1 BAND button
2 • Control dial
•
(standby/on attenuator) button
3 DISP (display) button
4 Remote sensor
• DO NOT expose the remote sensor to
strong light (direct sunlight or artificial
lighting).
5 Display window
6 5 (up) / ∞ (down) buttons
7 EQ (equalizer) button
8 0 (eject) button
9 USB (Universal Serial Bus) input terminal
p SRC (source) button
q
(control panel release) button
w SEL (select) button
e MODE button
r MO (monaural) button
t SSM (Strong-station Sequential Memory)
button
y Number buttons
u RPT (repeat) button
i RND (random) button
o
4/¢ buttons
Display window
; Track information indicators—TAG (ID3
Tag),
(track/file), (folder)
a Tuner reception indicators—ST (stereo),
MO (monaural)
s Main display
d Tr (track) indicator
f LOUD (loudness) indicator
g Source display / Volume level indicator
h Playback mode / item indicators—
RND (random),
(disc), (folder),
RPT (repeat)
j Track type indicators*—WMA, MP3
k Playback source indicators*—
CH: Lights up only when CD-CH is selected
as the playback source.
DISC: Lights up for the built-in CD player.
l EQ (equalizer) indicator
/ Sound mode (C-EQ: custom equalizer)
indicators—USER, ROCK, CLASSIC,
POPS, HIP HOP, JAZZ
•
also works as the time countdown
indicator and level meter during play (see
page 13).
*
lights up for the selected item.
Parts identification
Display window
Control panel
EN02-05KD-G725[UN]5.indd 4EN02-05KD-G725[UN]5.indd 4 12/6/05 5:44:57 PM12/6/05 5:44:57 PM
