Front board
Block No. [0][2][0][0]
PP1 QZW0010-001 STYLE PIN
PP5 QZW0010-001 STYLE PIN
TU1 QAU0312-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 LC75878W IC
IC602 RPM7338-V4 REMOCON RCV
Q641 2SB624/4/-X TRANSISTOR
Q643 UN2211-X TRANSISTOR
Q644 UN2211-X TRANSISTOR
D601 SML-310LT/MN/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D620 SML-310VT/JK/-X LED
D621 SML-310VT/JK/-X LED
D622 SML-310VT/JK/-X LED
D623 SML-310VT/JK/-X LED
D624 SML-A12BC2T-X BLUELED
D625 SML-A12BC2T-X BLUELED
D641 NSPW310BS/BRS/ LED
D642 NSPW310BS/BRS/ LED
D643 NSPW310BS/BRS/ LED
D650 UDZS9.1B-X Z DIODE
D651 UDZS5.1B-X Z DIODE
D652 1SS355-X SI DIODE
D653 1SS355-X SI DIODE
D654 1SS355-X SI DIODE
D655 1SS355-X SI DIODE
D656 1SS355-X SI DIODE
D657 1SS355-X SI DIODE
D658 1SS355-X SI DIODE
D680 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
C601 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C608 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C609 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C610 NBE21CM-475X TA E CAPACITOR 4.7uF 16V M
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C680 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R607 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R611 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R614 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R615 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R622 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R624 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R625 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R628 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R630 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R632 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R633 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R636 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R638 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R639 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R642 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R644 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R645 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R647 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R649 NRSA02J-561X MG RESISTOR 560
Ω
1/10W J
R651 NRSA02J-621X MG RESISTOR 620
Ω
1/10W J
R654 NRSA02J-621X MG RESISTOR 620
Ω
1/10W J
R655 NRS181J-431X MG RESISTOR 430
Ω
1/8W J
R656 NRS181J-431X MG RESISTOR 430
Ω
1/8W J
R657 NRS181J-431X MG RESISTOR 430
Ω
1/8W J
R658 NRS181J-471X MG RESISTOR 470
Ω
1/8W J
R659 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R660 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R661 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R665 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R666 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R667 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R668 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R669 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R670 NRSA63J-394X MG RESISTOR 390k
Ω
1/16W J
R671 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R672 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R673 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R674 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R675 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R676 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R677 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R678 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R679 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R680 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R681 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R685 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R690 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN601 NNZ0098-001X CAR CONNECTOR
JS601 QSW0793-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S690 NSW0124-001X TACT SW
SD601 NSW0218-001X LUMISWITCH
SD602 NSW0218-001X LUMISWITCH
TH685 NAD0022-103X N THERMISTOR 10k
Ω
10mW F
