3-7
Electrical parts list
Main board (KD-S51J)
Block No. [0][1]
Symbol
No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC S51J
IC161 TDA7404D-E-X IC S51J
IC251 NJM4565M-WE IC S51J
IC271 CD4066BPW-X IC S51J
IC291 CD4066BPW-X IC S51J
IC301 TB2906HQ IC S51J
IC701 UPD784217AGC322 IC S51J
IC702 IC-PST3433U-X IC S51J
IC771 BR24L16F-W-X IC S51J
IC801 HD74HC126FP-X IC S51J
IC901 HA13164A IC S51J
Q1 KTD1304-X TRANSISTOR S51J
Q5 2SB709A/R/-X TRANSISTOR S51J
Q6 2SB624/4/-X TRANSISTOR S51J
Q7 UN2211-X TRANSISTOR S51J
Q8 UN2211-X TRANSISTOR S51J
Q31 UN2211-X TRANSISTOR S51J
Q241 2SD601A/R/-X TRANSISTOR S51J
Q272 UN2111-X TRANSISTOR S51J
Q273 UN2211-X TRANSISTOR S51J
Q274 UN2211-X TRANSISTOR S51J
Q291 UN2211-X TRANSISTOR S51J
Q292 UN2211-X TRANSISTOR S51J
Q321 KTD1304-X TRANSISTOR S51J
Q331 KTD1304-X TRANSISTOR S51J
Q341 KTD1304-X TRANSISTOR S51J
Q351 KTD1304-X TRANSISTOR S51J
Q701 UN2211-X TRANSISTOR S51J
Q702 UN2211-X TRANSISTOR S51J
Q703 UN2211-X TRANSISTOR S51J
Q704 UN2211-X TRANSISTOR S51J
Q705 UN2211-X TRANSISTOR S51J
Q781 UN2111-X TRANSISTOR S51J
Q782 KTD1304-X TRANSISTOR S51J
Q784 UN2111-X TRANSISTOR S51J
Q881 UN2211-X TRANSISTOR S51J
Q901 2SB1132/QR/-W TRANSISTOR S51J
Q976 UN2211-X TRANSISTOR S51J
Q977 2SB709A/QR/-X TRANSISTOR S51J
D1 MA111-X SI DIODE S51J
D2 MA111-X SI DIODE S51J
D4 MA111-X SI DIODE S51J
D5 MA111-X SI DIODE S51J
D242 MA111-X SI DIODE S51J
D243 RB160M-30-X SB DIODE S51J
D244 UDZS5.1B-X Z DIODE S51J
D251 UDZS4.7B-X Z DIODE S51J
D273 MA111-X SI DIODE S51J
D321 MA111-X SI DIODE S51J
D325 UDZS11B-X Z DIODE S51J
D331 MA111-X SI DIODE S51J
D341 MA111-X SI DIODE S51J
D351 MA111-X SI DIODE S51J
D701 MA8062/M/-X Z DIODE S51J
D702 MA8062/M/-X Z DIODE S51J
D703 MA8062/M/-X Z DIODE S51J
D704 MA8062/M/-X Z DIODE S51J
D705 MA8062/M/-X Z DIODE S51J
D706 MA8062/M/-X Z DIODE S51J
D707 MA8062/M/-X Z DIODE S51J
D708 MA8062/M/-X Z DIODE S51J
D709 MA8062/M/-X Z DIODE S51J
D710 MA111-X SI DIODE S51J
D711 MA8062/M/-X Z DIODE S51J
D713 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J S51J
D714 SML-310VT/JK/-X LED S51J
D715 SML-310VT/JK/-X LED S51J
D716 SML-310VT/JK/-X LED S51J
D781 MA111-X SI DIODE S51J
D782 MA111-X SI DIODE S51J
D783 MA111-X SI DIODE S51J
D784 UDZS11B-X Z DIODE S51J
D901 1N5401-F64 DIODE S51J
D902 MA111-X SI DIODE S51J
D971 RB160M-30-X SB DIODE S51J
D972 RB160M-30-X SB DIODE S51J
D996 RB160M-30-X SB DIODE S51J
D997 RB160M-30-X SB DIODE S51J
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M S51J
C2 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C3 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C4 QERF1AM-227Z E CAPACITOR 220uF 10V M S51J
C5 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M S51J
C6 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C9 QEKJ1CM-226Z E CAPACITOR 22uF 16V M S51J
C10 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C11 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C12 QERF1AM-227Z E CAPACITOR 220uF 10V M S51J
C30 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C31 QERF1AM-107Z E CAPACITOR 100uF 10V M S51J
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J S51J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M S51J
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K S51J
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J S51J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J S51J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J S51J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K S51J
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K S51J
C40 QERF1CM-106Z E CAPACITOR 10uF 16V M S51J
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K S51J
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J S51J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K S51J
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K S51J
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K S51J
C49 NCB31HK-102X C CAPACITOR 1000pF 50V K S51J
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J S51J
C51 NCB31HK-331X C CAPACITOR 330pF 50V K S51J
C81 QERF1HM-105Z E CAPACITOR 1uF 50V M S51J
C82 NCB31HK-682X C CAPACITOR 6800pF 50V K S51J
C84 NCB31EK-103X C CAPACITOR 0.01uF 25V K S51J
C85 NCB31EK-153X C CAPACITOR 0.015uF 25V K S51J
C91 QERF1HM-105Z E CAPACITOR 1uF 50V M S51J
C92 NCB31HK-682X C CAPACITOR 6800pF 50V K S51J
C94 NCB31EK-103X C CAPACITOR 0.01uF 25V K S51J
C95 NCB31EK-153X C CAPACITOR 0.015uF 25V K S51J
C161 QEKJ1HM-105Z E CAPACITOR 1uF 50V M S51J
C162 QERF1HM-105Z E CAPACITOR 1uF 50V M S51J
C163 QTE1H55-225Z E CAPACITOR 2.2uF 50V S51J
C171 QEKJ1HM-105Z E CAPACITOR 1uF 50V M S51J
C172 QERF1HM-105Z E CAPACITOR 1uF 50V M S51J
C173 QTE1H55-225Z E CAPACITOR 2.2uF 50V S51J
C179 QERF1CM-476Z E CAPACITOR 47uF 16V M S51J
C181 QERF1CM-107Z E CAPACITOR 100uF 16V M S51J
C182 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C184 NCB31CK-224X C CAPACITOR 0.22uF 16V K S51J
C241 QERF1HM-105Z E CAPACITOR 1uF 50V M S51J
C242 QERF1CM-226Z E CAPACITOR 22uF 16V M S51J
C243 NCB31EK-473X C CAPACITOR 0.047uF 25V K S51J
C245 QERF1HM-224Z E CAPACITOR 0.22uF 50V M S51J
C251 NCB31HK-822X C CAPACITOR 8200pF 50V K S51J
C252 QERF0JM-476Z E CAPACITOR 47uF 6.3V M S51J
C253 QERF1CM-106Z E CAPACITOR 10uF 16V M S51J
C254 NCB31EK-823X C CAPACITOR 0.082uF 25V K S51J
C255 QERF1CM-476Z E CAPACITOR 47uF 16V M S51J
C256 NCB31EK-104X C CAPACITOR 0.1uF 25V K S51J
C262 QERF1HM-225Z E CAPACITOR 2.2uF 50V M S51J
C274 NCB31EK-223X C CAPACITOR 0.022uF 25V K S51J
C275 NCB31EK-223X C CAPACITOR 0.022uF 25V K S51J
C276 NCB31EK-223X C CAPACITOR 0.022uF 25V K S51J
C277 NCB31EK-562X C CAPACITOR 5600pF 25V K S51J
Symbol
No.
Part No. Part Name Description Local
