KD-SH9105
3-6
Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC101 AK7740VT IC
IC131 NJM4565V-X IC
IC151 TDA7404D-X IC
IC152 BU4066BCFV-X IC
IC171 BA3220FV-X IC
IC231 NJM4565V-X IC
IC251 TDA7404D-X IC
IC252 BU4066BCFV-X IC
IC271 BA3220FV-X IC
IC301 TDA7560-8U IC
IC331 NJM4565V-X IC
IC351 NJM4565V-X IC
IC352 BU4066BCFV-X IC
IC431 NJM4565V-X IC
IC701 UPD784217AGC227 IC
IC702 BD4833FVE-W IC
IC703 BR24L16F-W-X IC
IC911 HA13166 IC
IC931 NJM2360AM-X IC
IC941 HD74HCT126T-X IC
IC981 BA6956AN IC
Q21 2SB815/7/-X TRANSISTOR
Q22 2SB815/7/-X TRANSISTOR
Q23 UN2211-X TRANSISTOR
Q101 UN2211-X TRANSISTOR
Q102 2SB815/7/-X TRANSISTOR
Q103 UN2211-X TRANSISTOR
Q104 UN2211-X TRANSISTOR
Q105 UN2211-X TRANSISTOR
Q151 UN2211-X TRANSISTOR
Q152 UN2211-X TRANSISTOR
Q301 UN2211-X TRANSISTOR
Q302 2SD601A/QR/-X TRANSISTOR
Q321 2SD1048/6-7/-X TRANSISTOR
Q322 2SD1048/6-7/-X TRANSISTOR
Q351 UN2211-X TRANSISTOR
Q352 UN2211-X TRANSISTOR
Q353 2SD1048/6-7/-X TRANSISTOR
Q381 2SD601A/QR/-X TRANSISTOR
Q421 2SD1048/6-7/-X TRANSISTOR
Q422 2SD1048/6-7/-X TRANSISTOR
Q701 UN2213-X DIGI TRANSISTOR
Q911 UN2111-X TRANSISTOR
Q912 UN2211-X TRANSISTOR
Q913 2SB709A/QR/-X TRANSISTOR
Q914 2SD601A/QR/-X TRANSISTOR
Q915 UN2211-X TRANSISTOR
Q961 UN2211-X TRANSISTOR
Q971 UN2111-X TRANSISTOR
Q972 UN2111-X TRANSISTOR
Q981 UN2211-X TRANSISTOR
Q982 UN2211-X TRANSISTOR
Q983 UN2211-X TRANSISTOR
Q984 UN2211-X TRANSISTOR
Q985 UN2213-X DIGI TRANSISTOR
Q986 UN2211-X TRANSISTOR
Q991 UN2214-X TRANSISTOR
Q992 UN2211-X TRANSISTOR
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D21 MA152WK-X SI DIODE
D311 RB160M-30-X SB DIODE
D312 RB160M-30-X SB DIODE
D313 RB160M-30-X SB DIODE
D314 RB160M-30-X SB DIODE
D321 1SS355-X SI DIODE
D322 1SS355-X SI DIODE
D331 UDZS5.1B-X Z DIODE
D352 MA152WK-X SI DIODE
D353 UDZS5.1B-X Z DIODE
D381 1SS355-X SI DIODE
D382 1SS355-X SI DIODE
D411 RB160M-30-X SB DIODE
D412 RB160M-30-X SB DIODE
D413 RB160M-30-X SB DIODE
D414 RB160M-30-X SB DIODE
D421 1SS355-X SI DIODE
D422 1SS355-X SI DIODE
D431 UDZS5.1B-X Z DIODE
D701 1SS355-X SI DIODE
D901 1N5401-F64 DIODE
D911 1SS355-X SI DIODE
D912 RB160M-30-X SB DIODE
D913 RB160M-30-X SB DIODE
D914 RB160M-30-X SB DIODE
D915 RB160M-30-X SB DIODE
D916 MA152WA-X DIODE
D931 RB160M-30-X SB DIODE
D932 RB160M-30-X SB DIODE
D971 1SS355-X SI DIODE
D972 UDZS11B-X Z DIODE
D981 UDZS4.7B-X Z DIODE
D982 SML-310FT/JKL/X LED
D983 SML-310FT/JKL/X LED
D991 UDZS6.2B-X Z DIODE
D992 UDZS6.2B-X Z DIODE
D993 UDZS6.2B-X Z DIODE
D994 UDZS6.2B-X Z DIODE
D995 UDZS6.2B-X Z DIODE
D996 UDZS6.2B-X Z DIODE
D997 UDZS6.2B-X Z DIODE
D998 UDZS6.2B-X Z DIODE
D999 1SS355-X SI DIODE
C1 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C2 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3 QERF1CM-476Z E CAPACITOR 47uF 16V M
C4 QERF1CM-476Z E CAPACITOR 47uF 16V M
C5 QERF1AM-107Z E CAPACITOR 100uF 10V M
C6 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C7 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C8 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C9 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C10 QERF1AM-107Z E CAPACITOR 100uF 10V M
C11 NCS31HJ-821X C CAPACITOR 820pF 50V J
C12 NCS31HJ-821X C CAPACITOR 820pF 50V J
C13 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C14 QERF1HM-104Z E CAPACITOR 0.1uF 50V M
C15 QERF1AM-107Z E CAPACITOR 100uF 10V M
C16 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C31 NDC31HJ-331X C CAPACITOR 330pF 50V J
C101 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C103 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C104 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C105 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C110 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C111 QERF1CM-106Z E CAPACITOR 10uF 16V M
C114 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C116 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C117 NDC31HJ-120X C CAPACITOR 12pF 50V J
C118 QERF1CM-106Z E CAPACITOR 10uF 16V M
C119 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C120 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C121 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C122 QERF1CM-106Z E CAPACITOR 10uF 16V M
C124 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C128 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C129 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C131 NCS31HJ-821X C CAPACITOR 820pF 50V J
C132 NCS31HJ-821X C CAPACITOR 820pF 50V J
C133 NDC31HJ-101X C CAPACITOR 100pF 50V J
C134 NDC31HJ-101X C CAPACITOR 100pF 50V J
C135 NCB31CK-104X C CAPACITOR 0.1uF 16V K
