3-14
Front board
Block No. [0][2][0][0]
TH901 NAD0036-224X N THERMISTOR 220k Ω
TH902 NAD0031-002X N THERMISTOR Ω
 TU1 QAU0325-001 TUNER PACK
X1 QAX0781-001Z CRYSTAL
X701 QAX0782-001Z CRYSTAL
X702 QAX0401-001 CRYSTAL 32.768KHz
X4001 NAX0664-001X CRYSTAL
 Symbol No. Part No. Part Name Description Local
IC461 RPM6938-SV4 IC
IC471 M68AW512ML70ND6 IC(DIGITAL)
IC481 SN74AHC2G08U-X IC
IC482 SN74AHC2G08U-X IC
IC483 SN74AHC2G08U-X IC
IC484 SN74AHC2G08U-X IC
IC491 LH28F320BFHET72 I.C(FLASH
 IC801 MN103S57GDD IC
IC881 IC-PST3424U-X IC
Q441 2SB709A/QR/-X TRANSISTOR
Q442 2SB709A/QR/-X TRANSISTOR
Q472 UN211L-X TRANSISTOR
Q481 UN2111-X TRANSISTOR
Q881 2SD601A/QR/-X TRANSISTOR
D401 UDZS6.2B-X Z DIODE
D402 UDZS6.2B-X Z DIODE
D403 UDZS6.2B-X Z DIODE
D404 UDZS6.2B-X Z DIODE
D405 UDZS6.2B-X Z DIODE
D406 UDZS6.2B-X Z DIODE
D407 UDZS6.2B-X Z DIODE
D408 UDZS6.2B-X Z DIODE
D410 SML-310LT/MN/-X LED
D411 SML-310LT/MN/-X LED
D412 SML-310LT/MN/-X LED
D413 SML-310LT/MN/-X LED
D414 SML-310LT/MN/-X LED
D415 SML-310LT/MN/-X LED
D416 SML-310LT/MN/-X LED
D417 SML-310LT/MN/-X LED
D418 NECW050A/BPQ/-X E CAPACITOR #NCVpF 0
D419 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D420 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D421 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D422 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D423 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D424 NECBB205/WQR/-X E CAPACITOR #NCVpF 0
D425 SML-310LT/MN/-X LED
D426 MA152WK-X SI DIODE
D434 UDZS6.2B-X Z DIODE
D441 MA152WK-X SI DIODE
D474 1SS400-X SI DIODE
D478 1SS400-X SI DIODE
D881 MA152WA-X DIODE
D882 1SS355-X SI DIODE
C461 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C471 NCS31HJ-471X C CAPACITOR 470pF 50V J
C472 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C473 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C481 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C483 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C491 NCS31HJ-471X C CAPACITOR 470pF 50V J
C492 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C493 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C801 NCF31CZ-473X C CAPACITOR 0.047uF 16V Z
C802 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C804 NCB31HK-102X C CAPACITOR 1000pF 50V K
C805 NCB31HK-102X C CAPACITOR 1000pF 50V K
 Symbol No. Part No. Part Name Description Local
C806 NCB31HK-102X C CAPACITOR 1000pF 50V K
C807 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C871 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C872 NCB31HK-102X C CAPACITOR 1000pF 50V K
C873 NCB11EM-105X C CAPACITOR 1uF 25V M
C874 NCB31HK-102X C CAPACITOR 1000pF 50V K
C875 NQR0450-001X EMI FILTER 0.022uF 50V M
C876 NQR0450-001X EMI FILTER 0.022uF 50V M
C881 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C882 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C891 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C892 NCB31CK-473X C CAPACITOR 0.047uF 16V K
R408 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R409 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R410 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R411 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R412 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R413 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R414 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R415 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R416 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R417 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R418 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R420 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R422 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R424 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R426 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R427 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R428 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R429 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R430 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R431 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R432 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R433 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R434 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R441 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R442 NRSA63J-301X MG RESISTOR 300
Ω 1/16W J
R443 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R444 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R445 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R446 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R447 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R448 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R449 NRSA63J-301X MG RESISTOR 300
Ω 1/16W J
R450 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R451 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R452 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R453 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R454 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R455 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R456 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R463 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R464 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R482 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R483 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R492 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R801 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R802 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R803 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R804 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R805 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R806 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R807 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R808 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R809 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R810 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R811 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R813 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R814 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R815 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R816 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R817 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R818 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R819 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R820 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R821 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
