JVC KD-T402 Quick Start Guide

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Search for a station
1 Press B SRC repeatedly to select FM or AM.
2 Press S / T to search for a station automatically.
(or)
Press and hold S / T until “M” flashes, then press repeatedly to
search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1 to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the knob.
“MEMORY” appears once the station is stored.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob.
CD/USB/ANDROID
Start playback
The source changes automatically and playback starts when you load a disc
or attach a device (USB device/ Android device) to the USB input terminal.
To On the faceplate
Reverse/Fast-forward
Press and hold S / T.
Select a track/file
Press S / T.
Select a folder
Press 2 J / 1 K.
Repeat play
Press 4  repeatedly.
Random play
Press 3  repeatedly.
JS_JVC_QSG_KD_T409_E_EN_1.indd 6JS_JVC_QSG_KD_T409_E_EN_1.indd 6 6/13/2018 3:07:11 PM6/13/2018 3:07:11 PM

JVC KD-T402 Specifications

General

DIN size	1 DIN
Equalizer	Yes
Impedance	4 Ω
Output power	350 W
Product color	Black
Ready for iPod	No
Volume control	Rotary
Disc types supported	CD
Audio output channels	- channels
Equalizer bands quantity	15
Maximum power per channel	50 W
Mobile operating systems supported	Android
USB version	2.0
USB ports quantity	1
Audio formats supported	FLAC, MP3, WAV, WMA
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Illumination color	White
Package weight	1500 g

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	53 mm
Weight	1200 g
