KS-AX4700
3-6
Item
Parts number Parts name Area
Remarks
A
R 137 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 138 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 139 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 140 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 141 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 142 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 143 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 144 CAR1/5WJ3.9K RESISTOR CARBON FILM 1/5
R 145 CAR1/5WJ2.7K RESISTOR CARBON FILM 1/5
R 146 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 147 MET1/5WF12K RESISTOR METAL FILM 1/5W
R 148 MET1/5WF560 RESISTOR METAL FILM 1/5W
R 149 CAR1/5WJ220 RESISTOR CARBON FILM 1/5
R 150 CAR1/5WJ220 RESISTOR CARBON FILM 1/5
R 151 MET3W0.1 RESISTOR
R 152 MET3W0.1 RESISTOR
R 153 MET3W0.1 RESISTOR
R 154 MET3W0.1 RESISTOR
R 155 CAR1/5WJ1.5K RESISTOR CARBON FILM 1/5
R 156 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 157 CAR1/5WJ56K RESISTOR CARBON FILM 1/5
R 158 MET1/2WJ4.7 RESISTOR METAL FILM 1/2W
R 159 MET2WJ680 RESISTOR METAL FILM 2WJ
R 201 MET1/5WF22K RESISTOR METAL FILM 1/5W
R 202 MET1/5WF21.5K RESISTOR METAL FILM 1/5W
R 203 MET1/5WF22K RESISTOR METAL FILM 1/5W
R 205 MET1/5WF24K RESISTOR METAL FILM 1/5W
R 206 MET1/5WF24K RESISTOR METAL FILM 1/5W
R 208 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 209 MET1/5WF1.3K RESISTOR METAL FILM 1/5W
R 210 MET1/5WF15K RESISTOR METAL FILM 1/5W
R 211 CAR1/5WJ12K RESISTOR CARBON FILM 1/5
R 212 MET1/5WF56K RESISTOR METAL FILM 1/5W
R 213 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 214 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 215 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 216 CAR1/5WJ20K RESISTOR CARBON FILM 1/5
R 217 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 218 CAR1/5WJ5.6K RESISTOR CARBON FILM 1/5
R 219 CAR1/5WJ470K RESISTOR CARBON FILM 1/5
R 221 CAR1/5WJ30K RESISTOR CARBON FILM 1/5
R 222 CAR1/5WJ30K RESISTOR CARBON FILM 1/5
R 223 CAR1/5WJ30K RESISTOR CARBON FILM 1/5
R 224 CAR1/5WJ62K RESISTOR CARBON FILM 1/5
R 230 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 231 MET1/5WF5.6K RESISTOR METAL FILM 1/5W
R 232 MET1/5WF22K RESISTOR METAL FILM 1/5W
R 233 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 234 CAR1/5WJ5.6K RESISTOR CARBON FILM 1/5
R 235 CAR1/5WJ5.6K RESISTOR CARBON FILM 1/5
R 236 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 237 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 238 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 239 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 240 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 241 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 242 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 243 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 244 CAR1/5WJ3.9K RESISTOR CARBON FILM 1/5
R 245 CAR1/5WJ2.7K RESISTOR CARBON FILM 1/5
R 246 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 247 MET1/5WF12K RESISTOR METAL FILM 1/5W
R 248 MET1/5WF560 RESISTOR METAL FILM 1/5W
R 249 CAR1/5WJ220 RESISTOR CARBON FILM 1/5
R 250 CAR1/5WJ220 RESISTOR CARBON FILM 1/5
R 251 MET3W0.1 RESISTOR
R 252 MET3W0.1 RESISTOR
R 253 MET3W0.1 RESISTOR
R 254 MET3W0.1 RESISTOR
R 255 CAR1/5WJ1.5K RESISTOR CARBON FILM 1/5
R 256 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 257 CAR1/5WJ56K RESISTOR CARBON FILM 1/5
R 258 MET1/2WJ4.7 RESISTOR METAL FILM 1/2W
R 259 MET2WJ680 RESISTOR METAL FILM 2WJ
SV 01 GF06P-202 SEMI VOLUME 2K OHM
SW101 JSS-2319 SWITCH SLIDE SW
T 01 TF137061501 TRANS FORMER
TH 01 FTD5-350 THERMISTOR 50K NTC
U 01 TL494CN I.C PWM IC
U 101 NJM2068D I.C DUAL OP AMP
U 102 NJM2068LD I.C DUAL OP AMP
U 103 NJM2068LD I.C DUAL OP AMP
U 104 NJM2068LD I.C DUAL OP AMP
U 105 NJM2068LD I.C DUAL OP AMP
U 106 NJM2068LD I.C DUAL OP AMP
VR101 RK0971220-20KB2 VOLUME
VR102 RK0971220-20KB2 VOLUME
