5
Ÿ
• The attaching plate closes automatically about
10 seconds after the monitor panel is unlocked.
!
Detaching
~ While the unit is turned on:
The monitor panel opens by about 50°.
• It closes automatically when no operation is
done for about a minute.
Remove the monitor panel before this happens.
Attaching plate
The monitor panel is
unlocked.
Basic operations
Soft case (supplied)
• Hold the monitor panel securely so as not to drop it accidentally.
• Fit the monitor panel onto the attaching plate until it is firmly locked.
Caution:
Exit
Detach
Close
Yes
No
Detach?
Detaching/attaching the monitor panel
Attaching
EN_KW-AVX836[U]3.indb 5EN_KW-AVX836[U]3.indb 5 10.1.16 5:18:50 PM10.1.16 5:18:50 PM
