Chapter 5
14
A wall mount kit (purchased separately) would allow you to mount your JVC TV on the wall.
For detailed information on installing the wall mount, refer to the instructions provided by the wall
mount manufacturer. It is strongly recommended to contact a technician for professional assistance
for wall mount installation. JVC is not responsible for any damage to the product or injury to yourself
or others resulting from the wall-mounting.
Dimensions for Mounting Hole Pattern
- This JVC TV is compatible with a 200 mm x 100 mm mounting hole pattern.
- 4 pcs of type M5 screws are required for installing the wall mount bracket to your JVC TV. Do not use
screws that are longer than 30mm. Screws that are too long may cause damage to the inside of the TV set.
- Do not fasten the screws too tight for this may damage the TV or cause the TV to fall, resulting in personal
injury. JVC is not liable for these kinds of incidents.
- Do not mount your JVC TV at more that a 15 degree tilt.
- Always use two people to mount the TV to a wall.
- Don not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due
to electric shock.
100
200
