CAUTION:
• Make all connections before plugging the System into an AC power outlet.
Connecting the FM Antenna
Using the Supplied Wire Antenna
Using an FM 75-Ohm Antenna Cable (not Supplied)
If reception is poor, connect the outside antenna.
• Before attaching a 75 ohm coaxial lead (the kind with a round wire going to an outdoor antenna), disconnect the supplied
FM Wire Antenna.
ANTENNA
AM
LOOP
FM
AM
EXT
FM
75
GND GND
RIGHT
LEFT
AUX IN ANTENNA
AM
LOOP
FM
AM
EXT
FM
75
GND GND
LEFT
CAUTION:
SPEAKER IMPEDANCE 6 16 OHMS.
SPEAKERS
RIGHT
FM wire antenna (supplied)
Extend the supplied FM
Wire Antenna horizontally.
Strip vinyl shield from cut line,twist wire
core.
Outdoor FM antenna cable (not supplied)
