JVC RX-7030VBK Service Manual

3-8
Micon board
Block No. [0][3][0][0]
FL351 QQR0590-001 FILTER
FL352 QQR0590-001 FILTER
FS400 E3400-444 FELT SPACER
FS401 E3400-444 FELT SPACER
J201 QNN0011-001 PIN JACK
J202 QNN0011-001 PIN JACK
J204 QNN0017-002 PIN JACK
J241 QND0108-001 S-CONNECTOR
J242 QND0098-001 DIN CONNECTOR
J244 QND0107-001 S JACK
J371 QNN0018-002 PIN JACK
J372 QNN0018-002 PIN JACK
J373 QNN0546-001 PIN JACK
JS400 QSW1017-001 JOG VOLUME
JS401 QSW1015-001 ROTARY ENCODER
S400 QSW0683-001Z PUSH SW
S401 QSW0683-001Z PUSH SW
S402 QSW0683-001Z PUSH SW
S403 QSW0683-001Z PUSH SW
S404 QSW0683-001Z PUSH SW
S405 QSW0683-001Z PUSH SW
S406 QSW0683-001Z PUSH SW
S407 QSW0683-001Z PUSH SW
S408 QSW0683-001Z PUSH SW
S409 QSW0683-001Z PUSH SW
S411 QSW0683-001Z PUSH SW
S412 QSW0683-001Z PUSH SW
S414 QSW0683-001Z PUSH SW
S415 QSW0683-001Z PUSH SW
S416 QSW0683-001Z PUSH SW
S417 QSW0683-001Z PUSH SW
S418 QSW0683-001Z PUSH SW
S419 QSW0683-001Z PUSH SW
S421 QSW0683-001Z PUSH SW
S422 QSW0683-001Z PUSH SW
S424 QSW0683-001Z PUSH SW
S425 QSW0683-001Z PUSH SW
S426 QSW0683-001Z PUSH SW
S427 QSW0683-001Z PUSH SW
S429 QSW0683-001Z PUSH SW
S430 QSW0683-001Z PUSH SW
S431 QSW0683-001Z PUSH SW
S480 QSW0683-001Z PUSH SW
S481 QSW0683-001Z PUSH SW
S482 QSW0683-001Z PUSH SW
S483 QSW0683-001Z PUSH SW
X301 QAX0263-001Z CRYSTAL 4.332MHz
X400 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
PW12 QUB111-16PPPP WIRE
PW16 QUB116-16PPPP PIN WIRE
PW18 QUB112-28PPPP SIN TWIST WIRE
PW19 QUB111-28PPPP SIN TWIST WIRE
PW30 QUB116-28PPPP SIN TWIST WIRE
PW60 QUB111-28PPPP SIN TWIST WIRE
IC901 MN101C49GMG IC(MCU) System control
IC903 IC-PST9139-T IC
Q52 KTD863/Y/-T TRANSISTOR
Q53 KRC105M-T DIGI TRANSISTOR
Q71 KTA1046/Y/ TRANSISTOR
Q74 KTC3200/GL/-T TRANSISTOR
Q901 KRC107M-T TRANSISTOR
Q903 KRC105M-T DIGI TRANSISTOR
Q904 KRC105M-T DIGI TRANSISTOR
Q905 KRC105M-T DIGI TRANSISTOR
Q906 KRC105M-T DIGI TRANSISTOR
Q907 KRC105M-T DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q908 KRC105M-T DIGI TRANSISTOR
Q921 2SD2395/EF/ TRANTRANSISTOR
Q931 2SD2395/EF/ TRANTRANSISTOR
Q941 2SD2395/EF/ TRANTRANSISTOR
Q951 2SD2395/EF/ TRANTRANSISTOR
Q961 KTA1046/Y/ TRANSISTOR
Q971 2SD2395/EF/ TRANTRANSISTOR
 D51 11ES2-T4 DIODE
 D52 11ES2-T4 DIODE
 D53 11ES2-T4 DIODE
 D54 11ES2-T4 DIODE
D56 MTZJ6.2B-T2 Z DIODE
D57 1SS133-T2 DIODE
 D61 10E2-FD DIODE
 D62 11ES2-T4 DIODE
 D63 10E2-FD DIODE
 D64 11ES2-T4 DIODE
D71 11ES2-T4 DIODE
D72 11ES2-T4 DIODE
D73 11ES2-T4 DIODE
D74 MTZJ36C-T2 Z DIODE
D75 MTZJ8.2C-T2 Z DIODE
D900 11ES2-T4 DIODE
D901 11ES2-T4 DIODE
D902 11ES2-T4 DIODE
D904 1SS133-T2 DIODE
D921 MTZJ5.6C-T2 Z DIODE
D931 MTZJ6.2C-T2 Z DIODE
D941 MTZJ13C-T2 Z DIODE
D951 MTZJ13C-T2 Z DIODE
D955 1SS133-T2 DIODE
D956 1SS133-T2 DIODE
D961 MTZJ13C-T2 Z DIODE
D971 MTZJ10C-T2 Z DIODE
D975 1SS133-T2 DIODE
D976 1SS133-T2 DIODE
D977 1SS133-T2 DIODE
D978 1SS133-T2 DIODE
D979 1SS133-T2 DIODE
 C1 QCZ9104-472 C CAPACITOR 4700pF
C51 QFLC2AJ-472Z M CAPACITOR 4700pF 100V J
C52 QETM1EM-108 E CAPACITOR 1000uF 25V M
C54 QETN1CM-477Z E CAPACITOR 470uF 16V M
C55 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C61 QFN32AJ-104Z M CAPACITOR 0.1uF 100V J
C62 QFN32AJ-104Z M CAPACITOR 0.1uF 100V J
C63 QFN32AJ-104Z M CAPACITOR 0.1uF 100V J
C65 QETM1VM-338 E CAPACITOR 3300uF 35V M
C66 QETM1VM-108 E CAPACITOR 1000uF 35V M
C68 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C69 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C70 QETN1HM-227Z E CAPACITOR 220uF 50V M
C71 QETN1JM-107Z E CAPACITOR 100uF 63V M
C72 QETN1HM-226Z E CAPACITOR 22uF 50V M
C73 QETN1HM-226Z E CAPACITOR 22uF 50V M
C74 QETN1HM-105Z E CAPACITOR 1uF 50V M
C81 QFZ9076-104Z MM CAPACITOR 0.1uF
C91 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C92 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C901 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C902 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C903 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C904 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C905 QDVB1EZ-223Y C CAPACITOR 0.022uF 25V Z
C921 QETN1EM-107Z E CAPACITOR 100uF 25V M
C922 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C931 QETN1CM-477Z E CAPACITOR 470uF 16V M
C932 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C941 QETN1EM-107Z E CAPACITOR 100uF 25V M
C942 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C951 QETN1EM-107Z E CAPACITOR 100uF 25V M
C952 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C961 QETN1EM-107Z E CAPACITOR 100uF 25V M
C962 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C971 QETN1EM-337Z E CAPACITOR 330uF 25V M
C972 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
 Symbol No. Part No. Part Name Description Local
