JVC SP-PW880 - Electrical Parts List

SP-PW880
3-6
Item
Parts number Parts name Area
Remarks
Block No. 01
A
CN811 QGB2016J1-15 CONNECTOR TO WOOF.PWB
CN821 QGB2016K1-15 B TO B CONNE TO CONT.PWB
CN851 QGA2501C1-02 2P CONNECTOR FOR LED
CN881 QGA3901C1-02 CONNECTOR FOR SPK
CN891 QGA3901C1-05 5P CONNECTOR FOR SEC.POWER
CN899 QGA7901C1-02 CONNECTOR E,ENPRI MORE
CN899 QGA7901C1-04 CONNECTOR USPRI MORE
C8101 QTE1H28-106Z E CAPACITOR
C8102 QTE1H28-106Z E CAPACITOR
C8103 QDYB1CM-103Y C.CAPACITOR
C8104 QFVJ1HJ-394Z CAPACITOR .39MF 5% 50V
C8105 QFVJ1HJ-394Z CAPACITOR .39MF 5% 50V
C8106 QFVJ1HJ-334Z M.CAPACITOR .33MF 5% 50V
C8107 QFVC1HJ-563Z M.M.CAP .056MF 5% 50V
C8108 QFVJ1HJ-333Z CAPACITOR .033MF 5% 50V
C8109 QFV41HJ-473 CAPACITOR .047MF 5% 50V
C8110 QFN31HJ-332Z M CAPACITOR 3300PF 5% 50V
C8111 QTE1H28-106Z E CAPACITOR
C8112 QDVB1EZ-223Y C CAPACITOR
C8113 QDVB1EZ-223Y C CAPACITOR
C8114 QDGB1HK-102Y C CAPACITOR
C8115 QDGB1HK-102Y C CAPACITOR
C8116 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8121 QTE1H28-106Z E CAPACITOR
C8122 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C8201 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C8202 QTE1H28-107Z E CAPACITOR
C8203 QTE1H28-107Z E CAPACITOR
C8204 QTE1H28-106Z E CAPACITOR
C8205 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C8206 QENC1HM-225Z NP E.CAPA 2.2MF 20% 50V
C8207 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C8208 QFVJ1HJ-224Z CAPACITOR .22MF 5% 50V
C8209 QFVJ1HJ-224Z CAPACITOR .22MF 5% 50V
C8210 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C8211 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C8212 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C8213 QDCB1HK-8R2Y C CAPACITOR
C8214 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C8215 QTE1E28-107Z E CAPACITOR
C8217 QTE1H28-106Z E CAPACITOR
C8218 QTE1H28-106Z E CAPACITOR
C8219 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8231 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C8232 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C8233 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C8234 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C8252 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C8253 QDYB1CM-103Y C.CAPACITOR
C8501 QETN1EM-226Z E CAPACITOR 22MF 20% 25V
C8502 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C8503 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C8504 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C8505 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C8506 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C8507 QDYB1CM-103Y C.CAPACITOR
C8508 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C8701 QTE1E28-476Z E CAPACITOR
C8702 QTE1E28-476Z E CAPACITOR
C8703 QTE1E28-107Z E CAPACITOR
C8704 QTE1E28-107Z E CAPACITOR
C8801 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C8901 QFZ9040-683 M CAPACITOR
A
.068MF
C8911 QEZ0223-478 E CAPACITER
A
4700MF
C8912 QEZ0223-478 E CAPACITER
A
4700MF
C8914 QFV72AJ-104Z M.CAPA. .10MF 5% 100V
C8915 QFV72AJ-104Z M.CAPA. .10MF 5% 100V
C8917 QFV72AJ-104Z M.CAPA. .10MF 5% 100V
C8921 QETM1EM-688 E CAPACITOR
A
6800MF 20% 25V
C8922 QETM1EM-688 E CAPACITOR
A
6800MF 20% 25V
C8924 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C8925 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C8927 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C8928 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
D8201 MTZJ8.2C-T2 ZENER DIODE
D8202 MTZJ8.2C-T2 ZENER DIODE
D8205 MTZJ33C-T2 Z DIODE
D8206 MTZJ33C-T2 Z DIODE
D8207 1SS133-T2 SI DIODE
D8208 1SS133-T2 SI DIODE
D8209 1SS133-T2 SI DIODE
D8211 1N5402M-20 DIODE
A
D8212 1N5402M-20 DIODE
A
D8501 1SS133-T2 SI DIODE
D8502 1SS133-T2 SI DIODE
D8503 1SS133-T2 SI DIODE
D8504 1SS133-T2 SI DIODE
D8505 1SS133-T2 SI DIODE
D8506 1SS133-T2 SI DIODE
D8507 1SS133-T2 SI DIODE
D8508 1SS133-T2 SI DIODE
D8509 1SS133-T2 SI DIODE
D8510 1SS133-T2 SI DIODE
D8511 MTZJ6.8B-T2 ZENER DIODE
D8701 MTZJ10B-T2 ZENER DIODE
D8702 MTZJ10B-T2 ZENER DIODE
D8801 1SS133-T2 SI DIODE
D8911 D5SBA20-S1 SI DIODE
A
+/-35V
D8921 D5SBA20-S1 SI DIODE
A
+/-15V
D8924 DSK10C-T1 DIODE
A
IC811 NJM4580DD IC
IC812 NJM4580DD IC
IC813 NJM4580DD IC
IC821 STK411-290E IC
A
WOOFER AMP
IC851 TC74HCU04AP IC
IC861 UPC78L05J-T IC
J8101 QNN0090-001 PIN JACK
J8102 QNB0095-001 SPK TERMINAL
L8201 QQLZ005-R45 INDUCTOR
PP891 QNZ0079-001Z TAB
PP892 QNZ0079-001Z TAB
Q
8101 KTC3199/GL/-T TRANSISTOR
Q
8102 KTC3199/GL/-T TRANSISTOR
Q
8201 KTC3199/GL/-T TRANSISTOR
Q
8202 KTA1267/YG/-T TRANSISTOR
Q
8203 KTC3199/GL/-T TRANSISTOR
Q
8204 KTA1267/YG/-T TRANSISTOR
Q
8501 KTC3199/GL/-T TRANSISTOR
Q
8502 KTC3199/GL/-T TRANSISTOR
Q
8701 2SD400MP/EF/-T TRANSISTOR
A
Q
8702 2SB544MP(E,F) TRANSISTOR
A
Q
8801 2SC945QP TRANSISTOR
RY881 QSK0095-001 RELAY
A
R8101 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R8102 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R8103 QRE141J-563Y C RESISTOR 56K 5% 1/4W
Item
Parts number Parts name Area
Remarks
A
Electrical parts list(Main board)
A
A
A
Electrical parts list
