7 Center unit (XV-THM508/XV-THM303)
Audio section
Total Harmonic Distortion 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Digital input*
1
:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System: NTSC/PAL selectable
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V (0.3 V*
2
) (p-p)/75 C
Component-Y: 1.0 V(p-p)/75 C
Component-P
B/PR: 0.7 V(p-p)/75 C
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 C
S-video-Y: 1.0 V(p-p)/75 C
S-video-C: 0.286 V (0.3 V*
2
) (p-p)/75 C
*
2
For PAL system
Tuner section
Tuning Range
FM: 87.50 MHz to 108.00 MHz
AM: 531 kHz to 1 602 kHz
(at 9 kHz intervals)
530 kHz to 1 600 kHz
(at 10 kHz intervals)
General
Power Requirements: AC 110 – 240 V , 50/60 Hz
(except for Australia)
AC 240 V , 50 Hz
(for Australia only)
Power Consumption: 18 W (at operation)
2.0 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 380 mm
Mass: 4.3 kg
7 Subwoofer (SP-PWM508)
Amplifier section
Front/Center/Surround: 140 W per channel, RMS at 4 C
(Center/Surround)/ 140 W per channel,
RMS at 4 C (Front)
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 300 W, RMS at 4 C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 25 cm Bass-reflex, Magnetically
Shielded
Frequency Range: 20 Hz to 200 Hz
General
Power Requirements: AC 110 V/127 V/220 – 240 V
selectable with the voltage selector,
50 Hz/60 Hz
Power Consumption: 170 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
256 mm M 482 mm M 460 mm
Mass: 18.5 kg
7 Subwoofer (SP-PWM303)
Amplifier section
Front/Center/Surround: 80 W per channel, RMS at 6 C
(Center/Surround)/ 120 W per channel,
RMS at 4 C (Front)
at 1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 120 W, RMS at 4 C at 100 Hz, with 10
% total harmonic distortion.
Speaker section
Speaker unit: 16 cm Bass-reflex, Magnetically
Shielded
Frequency Range: 30 Hz to 200 Hz
General
Power Requirements: AC 110 V/127 V/220 – 240 V
selectable with the voltage selector,
50 Hz/60 Hz
(except for Australia)
AC 240 V , 50 Hz
(for Australia only)
Power Consumption: 110 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
168.5 mm M 412 mm M 444 mm
Mass: 12.0 kg
