JVC SP-UXG3 User Manual

3-22
Display board
Block No. [0][3]
R818 OW380100123315 C RESISTOR 1K Ω 1/8W
R819 OW380220223314 C RESISTOR 22K
Ω 1/8W
R820 OW380100123315 C RESISTOR 1K
Ω 1/8W
 R821 OW380022923504 C RESISTOR 2.2 Ω 1/4W
 R822 OW380022923504 C RESISTOR 2.2 Ω 1/4W
R823 OW380047923312 C RESISTOR 4.7
Ω 1/8W
R824 OW380047923312 C RESISTOR 4.7
Ω 1/8W
L801 OW152034004002 CHOKE COIL SPRING 2uH 34T
L802 OW152034004002 CHOKE COIL SPRING 2uH 34T
L803 OW152000068019 CHOKE COIL 6.8uH
L804 OW152000068019 CHOKE COIL 6.8uH
CN801 OW261061010034
CONNECTOR
WIRE
10P for MAIN
CN402
G3_UP
CN801 OW261061010045
CONNECTOR
WIRE
10P for MAIN
CN402
G3_UB,
G3_US,
G3_UT,G
3_UW,G
3_UY,G4
_A,G4_U
B,G4_US
,G4_UT,
G4_UW
CN802 OW261042041255
CONNECTOR
WIRE
4P for MAIN
CON801
LJ801 OW166004344011 FERRITE BEAD 700 100MHz
LJ802 OW166004344011 FERRITE BEAD 700 100MHz
LJ803 OW166004344011 FERRITE BEAD 700 100MHz
LJ804 OW166004344011 FERRITE BEAD 700 100MHz
XXXXX OW169004344117 FERRITE CORE For AC Cord
G3_UB,
G3_UB,
G3_UP,G
3_UP,G3
_UP,G3_
US,G3_U
S,G3_UT
,G3_UT,
G3_UW,
G3_UW,
G3_UY,G
3_UY,G4
_A,G4_A
,G4_UB,
G4_UB,
G4_US,
G4_US,
G4_UT,G
4_UT,G4
_UW,G4
_UW
XXXXX OW235020240011 UL WIRE
for Switch to
ACOut2
G3_UB,
G3_US,
G3_UT,G
3_UW,G
3_UY,G4
_UB,G4_
US,G4_U
T,G 4_ U
W
XXXXX OW182010212018 VOLTAGE SWITCH SL14-22AM5A
G3_UB,
G3_US,
G3_UT,G
3_UW,G
3_UY,G4
_UB,G4_
US,G4_U
T,G 4_ U
W
XXXXX OW235020047019 UL WIRE
G3_UB,
G3_US,
G3_UT,G
3_UW,G
3_UY,G4
_UB,G4_
US,G4_U
T,G 4_ U
W
XXXXX OW607000020007 EYELET D=2X4mm(x7)
XXXXX OW603000003022 CABLE TIE 4UL(x4)
XXXXX OW603000005029 CABLE TIE 6.5UL(x9)
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC701 OW510087261277 IC TMP87EP26F-4K G3_UP
IC701 OW510087261309 IC TMP87EP26F-4K
G3_UB,
G3_US,
G3_UT
IC701 OW510087261311 IC TMP87EP26F-4K
G3_UW,
G3_UY
IC701 OW510087261266 IC TMP87EP26F-4K G4_A
Q702 9013 TRANSISTOR OW343009013032
Q703 9013 TRANSISTOR OW343009013032
Q704 9013 TRANSISTOR OW343009013032
Q705 9013 TRANSISTOR OW343009013032
D701 1N4148 DIODE OW300004148072
D702 1N4148 DIODE OW300004148072
D703 1N4148 DIODE OW300004148072
D704 ELT-3142D LED OW313030022042
C701 OW120102527008 C CAPACITOR 1000pF 50V
C702 OW120104527009 C CAPACITOR 0.1uF 50V
C703 OW133103007014 E CAPACITOR 1000uF 6.3V
C704 OW133103007014 E CAPACITOR 1000uF 6.3V
C705 OW120104527009 C CAPACITOR 0.1uF 50V
C706 OW130101017114 E CAPACITOR 10uF 10V
C707 OW120104527009 C CAPACITOR 0.1uF 50V
C708 OW130222017112 E CAPACITOR 220uF 10V
C709 OW120102527008 C CAPACITOR 1000pF 50V
C713 OW120240526009 C CAPACITOR 24pF 50V
C714 OW120560526008 C CAPACITOR 56pF 50V
C715 OW120240526009 C CAPACITOR 24pF 50V
C716 OW120200526002 C CAPACITOR 20pF 50V
C717 OW120200526002 C CAPACITOR 20pF 50V
C718 OW130471017115 E CAPACITOR 47uF 10V
C721 OW130102017119 E CAPACITOR 100uF 10V
C722 OW130471017115 E CAPACITOR 47uF 10V
C723 OW120104527009 C CAPACITOR 0.1uF 50V
C724 OW120223527006 C CAPACITOR 0.022uF 50V
C725 OW120223527006 C CAPACITOR 0.022uF 50V
C728 OW120104527009 C CAPACITOR 0.1uF 50V
R702 OW390000029121 C RESISTOR 0
Ω 1/16W
R703 OW390100126102 C RESISTOR 1K
Ω 1/16W
R704 OW390100126102 C RESISTOR 1K
Ω 1/16W
R706 OW390150226101 C RESISTOR 15K
Ω 1/16W
R707 OW390100226108 C RESISTOR 10K
Ω 1/16W
R708 OW390100226108 C RESISTOR 10K
Ω 1/16W
R709 OW390100226108 C RESISTOR 10K
Ω 1/16W
R710 OW390330126102 C RESISTOR 3.3K
Ω 1/16W
R711 OW390220126104 C RESISTOR 2.2K
Ω 1/16W
R712 OW390100126102 C RESISTOR 1K
Ω 1/16W
R713 OW390100126102 C RESISTOR 1K
Ω 1/16W
R714 OW390100126102 C RESISTOR 1K
Ω 1/16W
R715 OW390100226108 C RESISTOR 10K
Ω 1/16W
R716 OW390100126102 C RESISTOR 1K
Ω 1/16W
R718 OW390100226108 C RESISTOR 10K
Ω 1/16W
R719 OW390100226108 C RESISTOR 10K
Ω 1/16W
R720 OW390100926105 C RESISTOR 10
Ω 1/16W
R721 OW390100226108 C RESISTOR 10K
Ω 1/16W
R722 OW390100226108 C RESISTOR 10K
Ω 1/16W
R723 OW390100226108 C RESISTOR 10K
Ω 1/16W
R724 OW390100226108 C RESISTOR 10K
Ω 1/16W
R725 OW390100226108 C RESISTOR 10K
Ω 1/16W
R726 OW390100226108 C RESISTOR 10K
Ω 1/16W
R727 OW390100226108 C RESISTOR 10K
Ω 1/16W
R728 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R729 OW390100126102 C RESISTOR 1K
Ω 1/16W
R730 OW390100126102 C RESISTOR 1K
Ω 1/16W
R731 OW390120126101 C RESISTOR 1.2K
Ω 1/16W
R732 OW390120126101 C RESISTOR 1.2K
Ω 1/16W
R733 OW390100226108 C RESISTOR 10K
Ω 1/16W
R734 OW390470926106 C RESISTOR 47
Ω 1/16W
R735 OW390100226108 C RESISTOR 10K
Ω 1/16W
R736 OW390100126102 C RESISTOR 1K
Ω 1/16W
R738 OW390100226108 C RESISTOR 10K
Ω 1/16W
R739 OW390100226108 C RESISTOR 10K
Ω 1/16W
