JVC TD-W254BK User Manual

TD-W254BK
3-2
Item
Parts number Parts name Ar
e
a
Electrical parts list
Remarks
Block No. 01
A
C 900 QCZ9105-472 CER.CAPACITOR EN
A
4700PF
C 901 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C 902 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C 903 QETM1EM-228 E CAPACITOR
A
2200MF 20% 25V
C 904 QETM1EM-228 E CAPACITOR
A
2200MF 20% 25V
C 906 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%
C 907 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 908 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 909 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 910 QETN1AM-337Z E CAPACITOR 330MF 20% 10V
C 911 QETN1AM-337Z E CAPACITOR 330MF 20% 10V
C 914 QETN1HM-337Z E CAPACITOR
A
330MF 20% 50V
C 915 QETN1HM-227Z E CAPACITOR 220MF 20% 50V
C 917 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 918 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 920 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 921 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 923 QETN1AM-337Z E CAPACITOR 330MF 20% 10V
C 924 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 927 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 928 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 930 QDYB1CM-103Y C.CAPACITOR
C 931 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C 941 QETN1HM-224Z E CAPACITOR .22MF 20% 50V
CN801 QGF1205C1-06 CONNECTOR
CN802 QGF1205C1-20 CONNECTOR
CN811 QGF1220F1-06 CONNECTOR
CN815 QGF1220F1-06 CONNECTOR
CN845 QGA2512C1-05Z CONNECTOR BIAS TEST POINT
CN861 QGB2003L1-05 CONNECTOR
CN862 QGB2003M2-05 CONNECTOR
CN901 QGD2501C1-05Z SOCKET I.M
A
C1101 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C1102 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1103 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1104 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C1105 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C1106 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1107 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C1108 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1151 QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V
C1152 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1153 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1154 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C1155 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C1156 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1169 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
C1251 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C1252 QFLC1HJ-472Z M CAPACITOR 4700PF 5% 50V
C1253 QETN1HM-334Z E CAPACITOR .33MF 20% 50V
C1254 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1255 QCS31HJ-471Z C CAPACITOR 470PF 5% 50V
C1256 QCS32HJ-151Z C CAPACITOR 150PF 5% 500V
C1257 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C1258 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C1261 QFLC1HJ-822Z M CAPACITOR 8200PF 5% 50V
C1262 QDX31EM-333Z C.CAPA I.M
C1263 QCB31HK-332Z C CAPACITOR 3300PF 10% 50V
C1264 QDX31EM-473Z C.CAPACITOR
C1265 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C1266 QDX31EM-273Z C.CAPA I.M
C1267 QDX31EM-123Z C.CAPA I.M
C1351 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C1354 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C1355 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C1356 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C1357 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C1358 QETN1HM-104Z 05CAPACITOR .10MF 20% 50V
C1359 QETN1HM-104Z 05CAPACITOR .10MF 20% 50V
C1360 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C1451 QFP32AJ-561Z PP CAPACITOR 560PF 5% 100V
C1452 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1453 QCS31HJ-561Z C CAPACITOR 560PF 5% 50V
C1454 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V
C1455 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C1456 QFLC1HJ-393Z M CAPACITOR .039MF 5% 50V
C1457 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C1501 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C1511 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C1601 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1602 QCB31HK-222Z C CAPACITOR 2200PF 10% 50V
C2101 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C2102 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2103 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2104 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C2105 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C2106 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2107 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C2108 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2151 QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V
C2152 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C2153 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2154 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C2155 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C2156 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2169 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
C2251 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C2252 QFLC1HJ-472Z M CAPACITOR 4700PF 5% 50V
C2253 QETN1HM-334Z E CAPACITOR .33MF 20% 50V
C2254 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C2255 QCS31HJ-471Z C CAPACITOR 470PF 5% 50V
C2256 QCS32HJ-151Z C CAPACITOR 150PF 5% 500V
C2257 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C2258 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C2261 QFLC1HJ-822Z M CAPACITOR 8200PF 5% 50V
C2262 QDX31EM-333Z C.CAPA I.M
C2263 QCB31HK-332Z C CAPACITOR 3300PF 10% 50V
C2264 QDX31EM-473Z C.CAPACITOR
C2265 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C2266 QDX31EM-273Z C.CAPA I.M
C2267 QDX31EM-123Z C.CAPA I.M
C2351 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C2354 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C2355 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C2356 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C2357 QFN31HJ-222Z M CAPACITOR 2200PF 5% 50V
C2358 QETN1HM-104Z 05CAPACITOR .10MF 20% 50V
C2359 QETN1HM-104Z 05CAPACITOR .10MF 20% 50V
C2360 QENC1EM-475Z NP E.CAPA I.M 4.7MF 20% 25V
C2451 QFP32AJ-561Z PP CAPACITOR 560PF 5% 100V
C2452 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2453 QCS31HJ-561Z C CAPACITOR 560PF 5% 50V
C2454 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V
C2455 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C2456 QFLC1HJ-393Z M CAPACITOR .039MF 5% 50V
C2457 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
(Main board)
Item
Parts number Parts name Ar
e
a
Remarks
A

JVC TD-W254BK Specifications

General

Brand	JVC
Model	TD-W254BK
Category	Cassette Player
Language	English
