JVC UX-A70MD User Manual

UX-A70MD
3-20
Item
Parts number Parts name Area
Remarks
A
Q
331 DTA114EKA-X DIGITAL.TRANSIS
Q
332 DTA113ZKA-X TRANSISTOR
Q
333 DTA113ZKA-X TRANSISTOR
Q
400 2SA1363/EF/-X TRANSISTOR
Q
401 2SA1363/EF/-X TRANSISTOR
Q
410 DTC114EKA-X TRANSISTOR
Q
411 DTC114EKA-X TRANSISTOR
R 300 NRSA63J-0R0X MG RESISTOR
R 301 NRS181J-0R0X MG RESISTOR
R 302 NRSA63J-0R0X MG RESISTOR
R 305 NRSA63J-222X MG RESISTOR
R 306 NRSA63J-474X MG RESISTOR
R 309 NRSA63J-474X MG RESISTOR
R 310 NRSA63J-331X MG RESISTOR
R 311 NRSA63J-183X MG RESISTOR
R 312 NRSA63J-103X MG RESISTOR
R 313 NRSA63J-104X MG RESISTOR
R 314 NRSA63J-133X MG RESISTOR
R 315 NRSA63J-243X MG RESISTOR
R 316 NRSA63J-104X MG RESISTOR
R 317 NRSA63J-103X MG RESISTOR
R 320 NRSA63J-563X MG RESISTOR
R 321 NRSA63J-331X MG RESISTOR
R 322 NRSA63J-331X MG RESISTOR
R 323 NRSA63J-331X MG RESISTOR
R 324 NRSA63J-102X MG RESISTOR
R 325 NRSA63J-472X MG RESISTOR
R 326 NRSA63J-331X MG RESISTOR
R 327 NRSA63J-331X MG RESISTOR
R 328 NRSA63J-101X MG RESISTOR
R 330 NRSA63J-8R2X MG RESISTOR
R 331 NRSA63J-270X MG RESISTOR
R 332 NRSA63J-473X MG RESISTOR
R 333 NRSA63J-473X MG RESISTOR
R 334 NRSA63J-473X MG RESISTOR
R 335 NRSA63J-473X MG RESISTOR
R 336 NRSA63J-104X MG RESISTOR
R 337 NRSA63J-1R0X MG RESISTOR
R 338 NRSA63J-4R7X MG RESISTOR
R 339 NRSA63J-473X MG RESISTOR
R 340 NRSA63J-222X MG RESISTOR
R 341 NRSA63J-222X MG RESISTOR
R 342 NRSA63J-222X MG RESISTOR
R 343 NRSA63J-102X MG RESISTOR
R 354 NRSA63D-103X MG RESISTER
R 355 NRSA63D-103X MG RESISTER
R 356 NRSA63J-102X MG RESISTOR
R 361 NRSA63J-102X MG RESISTOR
R 362 NRSA63J-102X MG RESISTOR
R 363 NRSA63J-102X MG RESISTOR
R 364 NRSA63J-102X MG RESISTOR
R 365 NRSA63J-102X MG RESISTOR
R 366 NRSA63J-102X MG RESISTOR
R 367 NRSA63J-102X MG RESISTOR
R 368 NRSA63J-102X MG RESISTOR
R 369 NRSA63J-102X MG RESISTOR
R 370 NRSA63J-104X MG RESISTOR
R 371 NRSA63J-103X MG RESISTOR
R 372 NRSA63J-103X MG RESISTOR
R 375 NRSA63J-103X MG RESISTOR
R 376 NRSA63J-104X MG RESISTOR
R 377 NRSA63J-684X MG RESISTOR
R 378 NRSA63J-332X MG RESISTOR
R 379 NRSA63J-102X MG RESISTOR
R 380 NRSA63J-105X MG RESISTOR
R 381 NRSA63J-102X MG RESISTOR
R 382 NRSA63J-151X MG RESISTOR
R 387 NRSA63J-331X MG RESISTOR
R 389 NRSA63J-331X MG RESISTOR
R 390 NRSA63J-331X MG RESISTOR
R 391 NRSA63J-561X MG RESISTOR
R 392 NRSA63J-102X MG RESISTOR
R 393 NRSA63J-102X MG RESISTOR
R 394 NRSA63J-102X MG RESISTOR
R 395 NRSA63J-102X MG RESISTOR
R 396 NRSA63J-331X MG RESISTOR
R 397 NRSA63J-331X MG RESISTOR
R 398 NRSA63J-331X MG RESISTOR
R 399 NRSA63J-331X MG RESISTOR
R 401 NRSA63D-153X MG RESISTOR
R 402 NRSA63D-562X MG RESISTER
R 403 NRSA63D-471X MG RESISTER
R 404 NRSA63D-333X MG RESISTER
R 420 NRSA63D-223X RESISTOR
R 421 NRSA63D-103X MG RESISTER
R 422 NRSA63D-223X MG RESISTER
R 423 NRSA63D-103X MG RESISTER
R 424 NRSA63D-223X MG RESISTER
R 425 NRSA63D-103X MG RESISTER
R 426 NRSA63D-223X MG RESISTER
R 427 NRSA63D-103X MG RESISTER
R 428 NRSA63D-153X MG RESISTOR
R 429 NRSA63D-392X MG RESISTER
R 430 NRSA63D-153X MG RESISTOR
R 431 NRSA63D-392X MG RESISTER
R 432 NRSA63D-123X MG RESISTOR
R 433 NRSA63D-822X MG RESISTER
R 434 NRSA63D-123X MG RESISTOR
R 435 NRSA63D-822X MG RESISTER
R 436 NRSA63J-223X MG RESISTOR
R 437 NRSA63J-302X MG RESISTOR
R 438 NRSA63J-223X MG RESISTOR
R 439 NRSA63J-302X MG RESISTOR
R 440 NRSA63D-103X MG RESISTER
R 441 NRSA63D-103X MG RESISTER
R 451 NRSA63J-473X MG RESISTOR
R 452 NRSA63J-563X MG RESISTOR
R 453 NRSA63J-1R0X MG RESISTOR
R 454 NRSA63J-1R0X MG RESISTOR
R 455 NRSA63J-223X MG RESISTOR
R 456 NAD0006-103X THERMISTOR
R 481 NRSA63J-100X MG RESISTOR
R 483 NRSA63J-0R0X MG RESISTOR
R 491 NRSA63J-471X MG RESISTOR
R 492 NRSA63J-471X MG RESISTOR
R 495 NRSA63J-471X MG RESISTOR
R 496 NRSA63J-471X MG RESISTOR
R 497 NRSA63J-1R0X MG RESISTOR
R 502 NRSA63J-332X MG RESISTOR
R 503 NRSA63J-103X MG RESISTOR
R 504 NRSA63J-333X MG RESISTOR
R 506 NRSA63J-473X MG RESISTOR
R 509 NRSA63J-104X MG RESISTOR
R 510 NRSA63J-102X MG RESISTOR
R 511 NRSA63J-102X MG RESISTOR
R 512 NRSA63J-102X MG RESISTOR
Electrical parts list (MD servo board)
Block No. 05
Item
Parts number Parts name Area
Remarks
A
