3-14
Primary board
Block No. [0][3]
C6101 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6102 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6103 NCB31CK-105X C CAPACITOR 1uF 16V K
C6104 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6107 NCB31HK-472X C CAPACITOR 4700pF 50V K 300UT,305UT
C6110 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C6111 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6112 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6113 NCB31CK-105X C CAPACITOR 1uF 16V K
C6114 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6117 NCB31HK-472X C CAPACITOR 4700pF 50V K 300UT,305UT
C6152 QEZ0863-106Z M CAPACITOR 10uF
C6201 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6202 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6203 NCB31CK-105X C CAPACITOR 1uF 16V K
C6204 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6207 NCB31HK-472X C CAPACITOR 4700pF 50V K 300UT,305UT
C6210 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C6211 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C6212 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6213 NCB31CK-105X C CAPACITOR 1uF 16V K
C6214 NCB31CK-474X C CAPACITOR 0.47uF 16V K
C6217 NCB31HK-472X C CAPACITOR 4700pF 50V K 300UT,305UT
C6401 QEZ0863-106Z M CAPACITOR 10uF
C6511 QEZ0863-106Z M CAPACITOR 10uF
C6601 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6602 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6611 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6613 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R6004 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6005 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV,
300A,300US,
300UW,300UG,
300UN
R6005 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J 300UF,300UT,
305UT
R6006 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R6007 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R6051 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R6052 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6101 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6103 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6111 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6113 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6151 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R6152 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6201 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6203 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6211 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R6213 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R6401 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6402 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6511 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6512 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R6602 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6603 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R6604 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R6612 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
L6101 QQLZ043-120 COIL 12uH
L6111 QQLZ043-120 COIL 12uH
L6201 QQLZ043-120 COIL 12uH
L6211 QQLZ043-120 COIL 12uH
L6301 QQR0797-002 COIL 300UT,305UT
L6302 QQR0797-002 COIL 300UT,305UT
CN605 QGF1208C1-11 CONNECTOR FFC/FPC (1-11)
CN640 QGA3901C1-02 CONNECTOR W-B (1-2)
EP600 E409182-001SM GRAND TERMINAL
J6001 QNB0303-001 SPK JACK
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC201 STR-W6765N IC
IC210 KIA431A-T IC
IC211 BD9305AFVM-W REGULATOR IC
 IC260 KIA7806API IC
IC360 LB1641 IC
IC700 GP1UE271XKC1 IC
IC720 PT6315 IC
Q2100 KRC102S-X DIGI TRANSISTOR
Q2103 RSR025P03-X MOSFET
Q2125 KTA1505/G/-X CHIP TR.
Q2126 KTC3265/Y/-X TRANSISTOR
Q2127 KRC104S-X TRANSISTOR
Q2131 KTA1504/YG/-X TRANSISTOR
Q2132 KRC104S-X TRANSISTOR
Q2160 KRC102S-X DIGI TRANSISTOR
Q2161 KRA102S-X DIGI TRANSISTOR
Q2303 KRA104S-X DIGI TRANSISTOR
Q2304 KTC3203/OY/-T TRANSISTOR
 D2001 KBJ4J BRIDGE DIODE
D2002 RG1C-LFA1 SI DIODE
D2003 RG1C-LFA1 SI DIODE
D2004 FR104S-T5 FR DIODE
D2005 FR104S-T5 FR DIODE
D2006 AL01Z-T4 DIODE
D2007 MTZJ11B-T2 Z DIODE
D2008 MA8220/M/-X Z DIODE
D2009 AL01Z-T4 DIODE
D2010 MA8056/M/-X Z DIODE
D2011 MA8075/M/-X Z DIODE
D2012 MA8062/M/-X Z DIODE
D2103 MA22D23-X SB DIODE
D2121 FR104S-T5 FR DIODE
D2125 MA8033-X Z DIODE
D2126 MA111-X SI DIODE
D2131 FR104S-T5 FR DIODE
D2134 MA8024-X Z DIODE
D2135 MA8300/M/-X Z DIODE
D2151 FMX-G22S DIODE
D2160 MA8047/M/-X Z DIODE
D2301 MA8039-X Z DIODE
D2302 MA8043/M/-X Z DIODE
D2600 1N4003S-T5 SI DIODE
D2601 1N4003S-T5 SI DIODE
D3650 MA8047/M/-X Z DIODE
D3656 1N4003S-T5 SI DIODE
D3657 1N4003S-T5 SI DIODE
D3658 1N4003S-T5 SI DIODE
D3659 1N4003S-T5 SI DIODE
D7000 SLI-343U8RC-T LED
D8000 STZC6.8N-X USB ESD DIODE
 PC201 PC123Y22FZ PHOTO COUPLER
 PC202 PC123Y22FZ PHOTO COUPLER
 C2001 QFZ9073-154 MM CAPACITOR 0.15uF AC250V M
 C2003 QCZ9134-101 C CAPACITOR 100pF
 C2004 QCZ9134-101 C CAPACITOR 100pF 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV,
300A,300US,
300UF,300UW,
300UG,300UN
 C2004 QCZ9134-221 M CAPACITOR 220pF 300UT,305UT
 C2007 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
C2008 QEZ0881-107 M CAPACITOR 100uF 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV,
300A,300UF
