JVC UX-H35 User Manual

(No.MB053)1-7
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the rear panel
(See Fig.1,2)
(1) From behind the body, remove the eight screws A attach-
ing the rear panel.
(2) Turing the body upside down, remove the two screws B at-
taching the rear panel, and remove.
Fig.1
Fig.2
A
A
A
A
BB
CC
Front panel assembly
Rear panel
