JVC UX-M5R User Manual

UX-M5R
UX-M5R
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
54 OW53-30000-09
KEY BUTTON
1
STOP/PROGRAM
55 OW43-30000-14
LENS FUNCTION
1
CD
56 OW43-30000-15
LENS FUNCTION
1
TUNER
57 OW43-30000-16
LENS FUNCTION
1
TAPE
58 OW68-30000-02
F.KEY FILTER 3
FUNCTION
59 OW53-30000-04
KEY BUTTON
1
FUNCTION
60 OW53-30000-01
KEY BUTTON
1
OPEN/CLOSE
61 OW48-30000-02
REMOTE SENSOR
1
63 OW53-30000-00
KEY BUTTON
1
STANDBY
64 OW53-30000-05
KEY BUTTON
1
VOLUME
65 OW48-30000-00
ORNAMENT
1
RING
66 OW49-00155-01
LACH CAM
1
67 OW36-00155-03A
COMPRESS SPRING
1
68 OW49-00155-02
LATCH CAM HOLDER
1
69 OW40-10408-81
SCREW
4
M4X8 BH
70 OW35-20001-01
TOOTH WASHER
4
71 OW35-00010-03
METAL WASHER
4
72 OW15-80005-00
POWER TRANS
A
1
EI-76 T05875A VDE
73 OW39-00006-02
TRANS M.BRACKET
1
75 OW84-30000-04
PCB LOCK SUPPORT
2
CS-0610
77 OW39-50000-00
BOTTOM CASE
1
78 OW30-00020-06E
AC POWER COARD
E,EN,EV
A
1
7 VDE BLK
OW30-00053-09
AC POWER COARD
B
A
1
6.5 MOULDED
79 OW87-50000-08
NAME PLATE
EV
1
OW87-50000-02
NAME PLATE
B,E,EN
1
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 OW84-10002-02
S.R BUSHING
A
1
SR-F41
2 OW40-23010-52
SCREW
10
M3X10 BH/MS
3 OW40-13012-01
SCREW
8
M3X12 BH/ST
4 OW61-30000-02
RIGHT SIDE PLATE 1
6 OW84-00006-01
PCB LOCK SUPPORT
1
RS-5
7 OW84-30000-02
PCB LOCK SUPPORT 1
RS-3
8 OW40-13008-91
SCREW 41
M3X8 BH/ST
9 OW40-03006-53
SCREW
4
M3X6 WH/MS TAP
10 OW61-50000-02
REAR CABINET
1
11 OW40-03008-53
SCREW
6
M3X8 WH/MS TAP
12 OW39-50000-01
HEAT SINK
1
13 OW39-50000-02
HEAT SINK
2
14 OW40-03006-81
SCREW
12
M3X6 BH/MS TAP
15 OW40-13012-03
SCREW
2
M3X12 WH/ST
16 OW60-30000-01
TOP CABINET
1
17 OW40-12608-21
SCREW
5
2.6X8 BH/ST
19 OW48-50000-01
MAIN PCB BRACKET
1
20 OW39-30000-03
CD REAR MOUNT BKT 1
21 OW84-30000-05
PCB LOCK SUPPORT
2
CS-0813
22 OW39-30000-01
CD F.MOUNT BKT 1
RIGHT
23 OW39-30000-00
CD F.MOUNT BKT
1
LEFT
24 OW98-00110-03
CD MECHA 1
TCP11TK4 +TD001
25 OW66-30000-04
CD DOOR
1
26 OW40-12605-21
SCREW 2
2.6X5 BH/ST
27 OW39-30000-02
CD F.MOUNT BKT
1
FRONT
28 OW61-30000-01
SIDE PLATE 1
LEFT
30 OW39-00013-00A
CDT13 HEAT SINK
1
31 OW48-30000-01
LCD BLACKET 1
32 OW68-50000-00
LIGHT GUIDE PAPER
1
33 OW43-30000-05
LIGHT GUIDE 1
35 OW68-30000-01
LCD FILTER
1
36 OW91-80005-00
LCD
1
92194TT-P YEEBO
37 OW43-30000-12
DISPLAY LENS 1
38 OW55-30000-00
BADGE 1
39 OW39-30000-04
FP MOUNT BRACKET 1
LEFT SIDE BASE
40 OW43-30000-11
CASS DOOR LENS
1
41 OW66-30000-01
CASS DOOR COVER 1
42 OW81-00155-01
RUBER FOOT
2
43 OW66-00155-03
TECHNICAL DOOR
1
44 OW39-30000-07
CASS TAPE SPRING
2
45 OW36-30000-00
TORSION SPRING
1
46 OW60-30000-07
FRONT CABINET
1
47 OW39-30000-05
FP MOUNT BRACKET
1
RIGHT SIDE BASE
48 OW39-00055-01
DECK MECHA BKT
1
49 OW94-33439-01
CASSETTE MECHA 1
12V/AUTO-REV
50 OW63-00155-01
DAMPER GEAR
1
51 OW39-00155-13
D.GERA HOLDER 2
53 OW53-30000-06
KEY BUTTON
1
RECORD/DIRECTION
