UX-M5R
3-9
Item
Parts number Parts name Ar
ea
Electrical parts list (CD&MCU board)
Remarks
Block No. 02
A
CN601 OW20-21100-00 CONNECTOR P=2MM 10PIN
CN602 OW20-21080-00 CONNECTOR P=2MM 8PIN
CN603 OW20-21030-00 CONNECTOR P=2MM 3PIN
CN604 OW20-41092-43 CONNECTOR P=2MM 9PIN
CN607 OW20-11060-00 CONNECTOR P=2MM 6PIN
CN608 OW20-21030-00 CONNECTOR P=2MM 3PIN
CN609 OW20-42032-13 CONNECTOR P=2.5MM 3PIN
CN701 OW20-12020-00 CONNECTOR P=2.5MM 2PIN
CN702 OW20-21020-00 CONNECTOR P=2MM 2PIN
CN703 OW20-21060-00 CONNECTOR P=2MM 6PIN
CN704 OW20-80160-00I CONNECTOR P=1MM 16PIN
C601 OW06-10477-00 E.CAPACITOR 470MF 10V
C602 OW06-10108-00 E.CAPACITOR 1000MF 10V
C602A OW05-07104-82B C.CAPACITOR 0.1MF 50V
C603 OW06-10227-00S E.CAPACITOR 220MF 10V
C605 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C606 OW05-07250-06T C.CAPACITOR 25PF
C607 OW05-07250-06T C.CAPACITOR 25PF
C608 OW05-07250-06T C.CAPACITOR 25PF
C609 OW05-07250-06T C.CAPACITOR 25PF
C610 OW06-10107-00S E.CAPACITOR 100MF 10V
C611 OW06-10107-00S E.CAPACITOR 100MF 10V
C612 OW06-10476-00S E.CAPACITOR 47MF 10V
C613 OW06-10107-00S E.CAPACITOR 100MF 10V
C614 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C615 OW06-50225-02 E.CAPACITOR 2.2MF 50V
C616 OW05-07271-10T C.CAPACITOR 270PF 10%
C617 OW05-07561-05 C.CAPACITOR 560PF NPO 5%
C618 OW06-10107-00S E.CAPACITOR 100MF 10V
C619 OW05-07330-06T C.CAPACITOR 33PF
C620 OW05-07330-06T C.CAPACITOR 33PF
C621 OW06-10107-00S E.CAPACITOR 100MF 10V
C622 OW06-10106-02 E.CAPACITOR 10MF 10V
C630 OW05-07102-10A C.CAPACITOR 1000PF
C641 OW06-10107-02 E.CAPACITOR 100MF 10V
C642 OW06-10476-02 E.CAPACITOR 47MF 10V
C643 OW06-16226-02 E.CAPACITOR 22MF 16V
C646 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C648 OW05-07223-82A C.CAPACITOR 0.022MF
C701 OW05-07103-20A C.CAPACITOR 0.01MF
C702 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C703 OW05-07223-82A C.CAPACITOR 0.022MF
C704 OW06-10227-00S E.CAPACITOR 220MF 10V
C705 OW06-10477-00 E.CAPACITOR 470MF 10V
C706 OW06-10106-00 E.CAPACITOR 10MF 10V
C707 OW06-10106-00 E.CAPACITOR 10MF 10V
C708 OW05-07222-82A C.CAPACITOR 2200PF
C709 OW06-10476-02 E.CAPACITOR 47MF 10V
C710 OW06-10226-02 E.CAPACITOR 22MF 10V
C711 OW05-07222-82A C.CAPACITOR 2200PF
C712 OW05-07473-82B C.CAPACITOR 0.047MF
C713 OW06-10476-00S E.CAPACITOR 47MF 10V
C714 OW06-10105-02 E.CAPACITOR 1MF 10V
C716 OW05-07473-82B C.CAPACITOR 0.047MF
C717 OW05-07150-06T C.CAPACITOR 15PF
C718 OW05-07150-06T C.CAPACITOR 15PF
C719 OW06-10476-00S E.CAPACITOR 47MF 10V
C720 OW05-07473-82B C.CAPACITOR 0.047MF
C721 OW05-07473-82B C.CAPACITOR 0.047MF
C722 OW06-10476-00S E.CAPACITOR 47MF 10V
C723 OW06-10476-00S E.CAPACITOR 47MF 10V
C724 OW06-16337-00 E.CAPACITOR 330MF 16V
C725 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C726 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C727 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C728 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C729 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C730 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C731 OW05-07473-82B C.CAPACITOR 0.047MF
C732 OW05-07473-82B C.CAPACITOR 0.047MF
C733 OW06-10476-00S E.CAPACITOR 47MF 10V
C736 OW05-07153-00 C.CAPACITOR 0.015MF
C737 OW05-07103-20A C.CAPACITOR 0.01MF
C738 OW05-07470-00A C.CAPACITOR 47PF
C739 OW05-07272-00 C.CAPACITOR 0.0027MF 50V 10%
C740 OW06-10476-00S E.CAPACITOR 47MF 10V
C741 OW05-02472-10 M.CAPACITOR 0.0047MF 10%
C742 OW05-07471-10A C.CAPACITOR 470PF
C743 OW05-07471-10A C.CAPACITOR 470PF
C744 OW05-07473-82B C.CAPACITOR 0.047MF
C746 OW05-02472-10 M.CAPACITOR 0.0047MF 10%
C747 OW06-10476-02 E.CAPACITOR 47MF 10V
C748 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C749 OW05-07473-82B C.CAPACITOR 0.047MF
C753 OW06-10227-02 E.CAPACITOR 220MF 10V
C754 OW06-10227-02 E.CAPACITOR 220MF 10V
C761 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C762 OW06-10106-02 E.CAPACITOR 10MF 10V
C763 OW06-50225-02 E.CAPACITOR 2.2MF 50V
C765 OW05-07103-20A C.CAPACITOR 0.01MF
C766 OW05-07103-20A C.CAPACITOR 0.01MF
C771 OW05-00560-06 C.CAPACITOR 56PF 5%
C772 OW05-07224-00 C.CAPACITOR 0.22MF
C773 OW05-07224-00 C.CAPACITOR 0.22MF
C774 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C775 OW05-07082-10A C.CAPACITOR 8.2PF
C776 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C777 OW06-10476-02 E.CAPACITOR 47MF 10V
C778 OW05-07104-82B C.CAPACITOR 0.1MF 50V
C779 OW06-10107-02 E.CAPACITOR 100MF 10V
C780 OW06-10476-02 E.CAPACITOR 47MF 10V
C781 OW05-07473-82B C.CAPACITOR 0.047MF
C790 OW06-16228-00 E.CAPACITOR 2200MF 16V
C791 OW05-07104-82B C.CAPACITOR 0.1MF 50V
D601 OW02-04148-00R DIODE IN4148
D602 OW02-04148-00R DIODE IN4148
D603 OW02-04148-00R DIODE IN4148
D604 OW02-04148-00R DIODE IN4148
D605 OW02-50091-00 ZENER DIODE 9.1V 0.5W
D606 OW02-50062-00 ZENER DIODE 6.2V 0.5W
D608 OW02-04148-00R DIODE IN4148
D609 OW02-50062-00 ZENER DIODE 6.2V 0.5W
D610 OW02-04001-00 DIODE 1N4001
D611 OW02-04148-00R DIODE IN4148
D702 OW02-50056-00 ZENER DIODE 5.6V 0.5W
D703 OW02-50062-00 ZENER DIODE 6.2V 0.5W
D704 OW02-04148-00R DIODE IN4148
D705 OW02-04148-00R DIODE IN4148
IC601 OW03-87261-15 IC TMP87EP26F-1J15
IC602 OW03-01924-00 IC BU1924F
IC701 OW03-09462-00 IC TC9462F
IC702 OW03-07291-00 T IC TA7291S
IC703 OW03-02092-00 T IC TA2092N
IC704 OW03-02153-00 T IC TA2153FN
L601 OW09-70102-00C INDUCTOR 100MH
L602 OW09-70102-00C INDUCTOR 100MH
Item
Parts number Parts name Ar
ea
Remarks
A
