– 14
HDS 7/16 HDS 8/18-4
Main Supply
Voltage V 400 220 400 220
Current type Hz 3~ 50 3~ 60 3~ 50 3~ 60
Connected load kW 4,7 4,7 6,0 6,0
Protection (slow) A 16 16 16 16
Type of protection -- IPX5 IPX5 IPX5 IPX5
Protective class -- I I I I
Maximum allowed net impedance Ohm -- -- -- --
Water connection
Max. feed temperature °C 30 30
Min. feed volume l/h (l/min) 900 (15) 1000 (16,7)
Suck height from open container (20 °C) m 0,5 0,5
Max. feed pressure MPa (bar) 1 (10) 1 (10)
Performance data
Water flow rate l/h (l/min) 270-660 (4,5-11) 300-800 (5-13,3)
Operating pressure of water (using standard
nozzle)
MPa (bar) 3-16 (30-160) 3-18 (30-180)
Max. excess operating pressure (safety valve) MPa (bar) 19,5 (195) 21,5 (215)
Steam flow rate l/h (l/min) 270-320
(4,5-5,3)
270-305
(4,5-5,1)
300-350
(5-5,8)
300-325
(5-5,4)
Max. operating pressure for working with steam
(using steam nozzle)
MPa (bar) 3,2 (32) 3,2 (32)
Part no. of steam nozzle -- 2.114-001.0 2.114-002.0
Max. operating temperature of hot water °C 98 98
Working temperature steam operation °C 155 155
Detergent suck in l/h (l/min) 0-39,6 (0-0,66) 0-48 (0-0,8)
Burner performance kW 51 61
Maximum consumption of heating oil kg/h 4,1 5,0
Max. recoil force of trigger gun N 32,4 41,4
Size of standard nozzle -- 040 040 043 043
Values determined as per EN 60335-2-79
Noise emission
Sound pressure level L
pA
dB(A) 77 73
Uncertainty K
pA
dB(A) 3 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 95 90
Hand-arm vibration value
Hand spray gun m/s
2
2,6 3,4
Spray lance m/s
2
4,2 3,4
Uncertainty K m/s
2
0,3 0,3
Fuel
Fuel -- Fuel oil EL or Diesel Fuel oil EL or Diesel
Amount of oil l 0,3 0,7
Oil grade -- SAE 90 SAE 90
Dimensions and weights
Length x width x height mm 1060 x 650 x 920 1060 x 650 x 920
Typical operating weight kg 118,1 126,1
Fuel tank l 15,5 15,5
Detergent Tank l 15,5 15,5
36 EN
