BR 400
12
English
Operating in normal mode
• Connect the unit plug to the extension cable and hook into the
cable grip on the push handle. Û
• Insert the extension cable plug into the mains socket.
• Turn knob to set brush contact pressure
to desired amount. Ü
Start at a low setting and increase pres-
sure as required.
• Press left or right operating lever. Û Brushes start to rotate.
• Press knob on top of push handle to supply detergent solution
to brush rollers. Operate button according to amount of dirt
on floor. Û
• Pull handle towards yourself. Brushes are lowered and cleaning
can begin.
• Make sure that brushes are kept wet.
Important: In order to avoid damage to the floor surface, please
observe the following:
1. Do not allow brushes to continue rotating on one spot during
the course of cleaning.
2. Make sure that only suitable brush rollers are used
(see Accessories).
• If the floor is to be dry after the cleaning process, the vacuum must
also be switched on.
– A foot pedal is situated on the chassis Ü. When the
pedal is pressed the suction beams are lowered
and the unit vacuums on both sides. The dirty
water collects in the dirty water tank.
Spray button
Left switch
lever
Right switch lever
Mains cable
brush contact pressure
high
low
Emptying the dirty water tank
• The dirty water collects in the lower tank.
– First remove the upper tank and place to one side, having
previously removed the hose.
– Then remove and empty the dirty water tank. When replacing
the tanks ensure that they are correctly mounted.
• Whenever the upper tank is filled, the dirty water tank must be
emptied.
• The anti-splash plates must always be inserted in the dirty water
tank.
Working with only brush
operation
• Pressing the foot pedal again ends the vacuuming and the
suction beams are raised:
– Stubborn dirt can be scrubbed vigorously.
– Special polishing brushes can polish floors dry.
