Kärcher HD 10/25-4 S Operating Manual

– 4
몇 WARNING
Observe regulations of water supplier.
According to applicable regula-
tions, the appliance must never be
used on the drinking water net
without a system separator. A suit-
able system separator by KÄRCHER or al-
ternatively a system separator according to
EN 12729 type BA must be used.
Water that was flowing through a system
separator is considered non-drinkable.
For connection values refer to technical
specifications.
 Connect the supply hose (minimum
length 7.5 m, minimum diameter 3/4“) to
the water connection point of the ma-
chine and at the water supply point (for
e.g. a tap).
Note:
The supply hose is not included.
 Open the water supply.
 Screw the suction hose with filter (order
no. 4.440-238.0) to the water connec-
tion.
 Deaerate the appliance:
Unscrew the nozzle.
Switch on the appliance and let it run
until the water exiting is bubble-free.
 Switch off the appliance and fit the noz-
zle again.
 DANGER
Risk of injury! Never use the appliance
without the spray lance attached. Check
and ensure proper fitting of the spray lance
prior to each use. The screw connection of
the spray lance must be finger-tight.
Risk of explosion!
Do not spray flammable liquids.
If the appliance is used in hazardous areas
(e.g. filling stations) the corresponding
safety regulations must be observed.
Risk of injury! Hold the hand spray gun and
the spray pipe firmly with both hands.
Risk of injury! The trigger and safety lever
may not be locked during the operation.
Risk of injury! Contact Customer Service if
the safety lever is damaged.
Risk of injury from high-pressure water jet.
Slide the safety catch on the trigger gun for-
ward before performing any work with the
appliance.
몇 CAUTION
Clean engines only at places with corre-
sponding oil separators (environmental
safety).
 To open the trigger gun: Actuate the
safety lever and trigger.
 To close the hand spray gun: Release
the safety lever and trigger.
Note:
The appliance is equipped with a pressure
switch. The motor starts up only when the
trigger gun is open.
 Set the appliance switch to "I".
Control lamp glows green.
 Release the trigger gun. To do so, push
the safety catch towards the back.
 Open the hand spray gun.
 DANGER
When adjusting the pressure/quantity regu-
lation, make sure that the screw connection
of the spray lance does not become loose.
 Set working pressure and flow rate
through turning (runless) at the pres-
sure- and amount regulation (B) (+/-).
Note:
For transporting small quantities, the en-
gine heat ensures that water is heated up to
approx. 15 °C.
몇 WARNING
Unsuitable detergents can cause damage
to the appliance and to the object to be
Water connection
Connection to the water supply
Drawing in water from open reservoirs
Operation
Opening/closing the trigger gun
High pressure operation
Only 1.286-907.0:
Operation with detergent
6 EN

Kärcher HD 10/25-4 S Specifications

General

Connected load	7500 W
AC input voltage	220 V
Number of phases	3
AC input frequency	60 Hz
Maximum pressure	209 bar
Working pressure (max)	190 bar
Working pressure (min)	30 bar

Weight and Dimensions

Depth	500 mm
Width	560 mm
Height	1090 mm
Weight	62000 g
