Please read and comply with these
original instructions prior to the ini-
tial operation of your appliance and store them
for later use or subsequent owners.
Before first start-up it is definitely necessary
to read the operating instructions and safe-
ty indications Nr. 5.951-949!
Notes about the ingredients (REACH)
You will find current information about the
ingredients at:
http://www.karcher.de/de/unternehmen/
umweltschutz/REACH.htm
Please unfold the front picture side
1 Storage compartment for nozzles
2 Handle
3 High pressure connection
4 Pressure/ quantity regulation
5 Water connection
6 Oil level indicator
7Oil tank
8Cover
9 Power switch
10 Fastening screw for device hood
11 Storage compartment for hoses
12 Handgun storage clip
13 Nozzle
14 Marking of the nozzle
15 Spray lance
16 Hand spraygun
17 Safety lever
18 Lever for hand spray gun
19 High pressure hose
20 Push handle
21 Cable clamp
22 Fastening screw for push-handle
23 Detergent suction hose with filter
24 Dosage valve for detergent
25 Accessory compartment
26 Hose drum
27 Crank
High-pressure jets can be dan-
gerous if improperly used. The
jet may not be directed at per-
sons, animals, live electrical equipment or
at the appliance itself.
According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.
Contents
Environmental protection EN - 1
Device elements EN - 1
Symbols on the machine EN - 1
Proper use EN - 2
Safety instructions EN - 2
Before Startup EN - 2
Operation EN - 4
Transport EN - 5
Storage EN - 5
Troubleshooting EN - 6
Accessories and Spare Parts EN - 6
Warranty EN - 7
CE declaration EN - 7
Technical specifications EN - 8
Environmental protection
The packaging material can be re-
cycled. Please do not throw the
packaging material into household
waste; please send it for recycling.
Old appliances contain valuable
materials that can be recycled;
these should be sent for recy-
cling. Batteries, oil, and similar
substances must not enter the
environment. Please dispose of
your old appliances using ap-
propriate collection systems.
Please do not release engine oil, fuel oil,
diesel and petrol into the environment Pro-
tect the ground and dispose of used oil in
an environmentally-clean manner.
Device elements
Symbols on the machine
32 EN
