Kärcher HDS 1000 DE User Manual

– 9
ATTENTION
Risk of damage! Never stop the motor un-
der full load when the trigger gun is opened.
 Set the appliance switch to "Burner off".
 Close the hand spray gun.
Motor regulates to reach dry run speed.
 Set the appliance switch at the engine
to OFF and close the fuel supply valve.
 Shut off water supply.
 Activate trigger gun until device is pres-
sure-less.
 Secure the hand spray gun using the
safety catch so that it doesn't open ac-
cidentally.
 Remove the water inlet hose from the
appliance.
몇 CAUTION
Risk of personal injury or damage! Consid-
er the weight of the appliance when storing
it.
ATTENTION
Protect the trigger from damage during
transport.
몇 CAUTION
Risk of personal injury or damage! Mind the
weight of the appliance during transport.
 When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
You can sign with your dealer a contract for
regular safety inspection or even sign a
maintenance contract. Please take advice
on this matter.
 DANGER
Risk of injury if the machine is left running
in an unattended state. Remove the spark
plug or disconnect the battery before work-
ing on the appliance.
Risk of burns! Do not touch hot silencers,
cylinders or radiator ribs.
 Check the high pressure hose for dam-
ages (risk of bursting). Please arrange
for the immediate exchange of a dam-
aged high-pressure hose.
 Check oil level of the high pressure
pump.
ATTENTION
Risk of damage! In case of lacteous oil in-
form Kärcher customer service immediate-
ly.
 Clean the sieve in the water connection.
 Clean sieve in the water shortage safe
guard.
 Clean filter at the detergent suck hose.
 Decalcify appliance.
 Have the maintenance of the device
performed by the customer service.
Oil change:
 Ready a catch bin for appr. 1 Liter oil.
 Turn out the oil drain screw.
 Drain the oil in a collection basin.
 Screw in the oil drain screw.
 Slowly fill in new oil until the "MAX"
marking on the oil container.
Note: Air pockets must be able to leak out.
For oil type refer to technical specifica-
tions.
Carry out maintenance tasks to the engine
according to the specifications provided in
the operating instructions of the engine
manufacturer.
Storage
Transport
Care and maintenance
Maintenance intervals
Daily
Weekly
Monthly
Every 500 operating hours, at least
annually
Maintenance Works
High-pressure pump
Dispose of old oil ecologically or turn it in at
a collection point.
Motor
12 EN

Kärcher HDS 1000 DE Specifications

General

Engine model	L 100 N
Power source	Diesel
Fuel tank capacity	5.5 L
Engine manufacturer	Yanmar
Working pressure (max)	200 bar
Working pressure (min)	40 bar
Heating oil/gas consumption (full load)	5.6 kg/h

Weight and Dimensions

Depth	750 mm
Width	1100 mm
Height	785 mm
Weight	185000 g
