Kärcher HDS 698 C ECO User Manual

– 11
Technical specifications
HDS 698 C ECO
Main Supply
Voltage V 380
Current type Hz 3~ 50
Connected load kW 4,5
Protection (slow) A 16
Water connection
Max. feed temperature °C 30
Min. feed volume l/h (l/min) 900 (15)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 0,6 (6)
Performance data
Water flow rate l/h (l/min) 300-700 (5-11,7)
Operating pressure of water (using standard
nozzle)
MPa (bar) 3,2-16 (32-160)
Max. excess operating pressure (safety valve) MPa (bar) 17,6 (176)
Steam flow rate l/h (l/min) 300 (5)
Max. operating pressure for working with
steam (using steam nozzle)
MPa (bar) 3,2 (32)
Part no. of steam nozzle -- 2.885-046
Max. operating temperature of hot water °C 98
Working temperature steam operation °C 98-155
Detergent suck in l/h (l/min) 0-12 (0-0,2)
Burner performance kW 50
Max. recoil force of hand spray gun N 34
Nozzle size -- 040
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 76
Uncertainty K
pA
dB(A) 1
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 92
Hand-arm vibration value
Hand spraygun m/s
2
2,6
Spray lance m/s
2
2,3
Uncertainty K m/s
2
1,0
Fuel
Fuel -- Fuel oil EL or Diesel
Amount of oil l 0,6
Oil grade -- Hypoid SAE 90 (6.288-016)
Dimensions and weights
Length x width x height mm 940 x 600 x 740
Weight without accessories kg 94
Fuel tank l 16
Detergent Tank l 8
29EN
