English 11
몇 CAUTION
Risk of personal injury or damage!
Consider the weight of the appliance when storing it.
Prior to extended storage periods, as during the winter,
also observe the instructions in the Care section.
 Park the machine on an even surface.
 Press the disconnect on the trigger gun and re-
move the high pressure hose from the trigger gun.
 Push the casing of the quick coupling for the high
pressure hose toward the rear and disconnect the
high pressure hose from the appliance.
 Insert the trigger gun in its holder.
 Engage the spray lance in its compartment.
 Suspend the high-pressure hose into its holder.
 Roll up the power cord and loop it e.g. round the
handle.
ATTENTION
Appliances and accessories that are not completely
drained can be destroyed by frost. Completely drain ap-
pliance and accessories and protect them against frost.
To avoid damage:
 Completely drain all water from the appliance:
Switch the appliance on with detached high pres-
sure hose and detached water supply (max. 1 min-
ute) and wait, until no more water exits at the high
pressure connection. Turn off the appliance.
 Store the appliance and the entire accessories in a
frost free room.
 DANGER
Risk of electric shock.
 Prior to all work on the appliance, switch off the ap-
pliance and pull the power plug.
Clean the sieve in the water connection regularly.
ATTENTION
The sieve must not be damaged.
 Remove coupling from the water connection.
Illustration
 Pull the sieve out using flat pliers.
 Clean the sieve under running water.
 Reinsert the sieve into the water connection.
Prior to longer periods of storage, e.g. in the winter:
 Remove filter from suction hose for detergent and
clean under running water.
The high pressure hose is specially constructed with re-
inforced walls to handle water pressure up to 11 MPa
(1600 psi) - it can be easily damaged and should be
stored carefully.
 Do not kink.
 Do not drive vehicles over the hose.
 Do not expose the hose to sharp edges or corners.
Misuse will lead to ballooning or premature failure and
will invalidate warranty.
Storage
Storing the Appliance
Frost protection
Care and maintenance
Clean the sieve in the water connection
Cleaning the detergent filter
High pressure hose
