9. TECHNICAL DATA
Power Connection
Voltage ........................................................ 230-240 V (AC)
Current.............................................................. 1~50 Hz
Connected/Load .................................................. 2.0 KW
Mains Fuse ........................................................... 13 AMP
Water Connection
Supply Temperature (Max)................................... 40 °C
Supply Rate (Min)................................................. 10 litres per minute
Supply Pressure (Max) ........................(6 bar)...... 0,6 MPa
Supply Hose Length ............................................ 7.5 metres
Diameter ......................................... 1/2 inch
Suction Height from open tank
at Water Temperature 20 °C .................................. 1 metre
Performance Data
Pump Pressure (Max. at bypass) .... (130 bar) ....... 13 MPa
Operating Pressure .................... (20-120 bar) ... 2-12 MPa
Flow Rate ........................................ (420 l/h) .......7,0 litres per minute
Detergent Intake .................................................. 0,4 litres per minute
Recoil Force of Spray Gun
at Operating Pressure .......................................... 22 N
Optimum Working Distance on High Pressure..... 30 cm
Unit vibrations (ISO 5349) ..........................................0,8 m/s²
Sound pressure level L
PA
(EN 60704-1) ...................... 72 dB(A)
Sound power level L
WA
(2000/14/EC) .......................... 87 dB(A)
Dimensions
Length..................................................................... 438 mm
Width ...................................................................... 411 mm
Height ..................................................................... 936 mm
Weight ...................................................................... 16 Kg
Circuit Diagramm
C1 Running capacitor
F1 Temperature fuse
M1 Motor
S1 Appliance switch
S2 Pressure-operated switch
