Kärcher K 5.68 M User Manual

42 Français
INSTRUCTIONS DE MONTAGE

Kärcher K 5.68 M Specifications

General

Flow Rate	460 l/h
Hose Length	9 m
Cable Length	5 m
Max. Inlet Temperature	40 °C
Dimensions (L × W × H)	349 x 426 x 878 mm
Voltage	230 V
Frequency	50 Hz
Power	2.1 kW
Pressure	20-140 bar / 2-14 MPa

Summary

Safety Alert Symbols

Important Safety Instructions

Risk of Injection or Injury

High pressure jets can be dangerous if misused. Do not direct at persons, animals, or electrical devices.

Risk of Electrocution

Keep connections dry, do not touch plug with wet hands, use individual branch circuit only.

Risk of Explosion

Do not spray flammable liquids or use acids, alkaline, solvents, or flammable material.

Water Supply (Cold Water Only)

Assembly Instructions

Operating Instructions

Step 1: Connect High Pressure Hose

Connect the high pressure hose to the unit's high pressure outlet.

Step 2: Insert Spray Wand

Insert the spray wand into the trigger gun and twist to lock.

Step 3: Connect Garden Hose

Connect the garden hose to the unit's water inlet.

Step 4: Connect to Water Source

Connect garden hose to cold water source and turn water on.

Step 5: Plug in Power Cord

Plug the power cord into the electrical outlet.

Step 6: Purge Air

Unlock safety, trigger gun to release trapped air until steady water flow.

Step 7: Turn on Washer

Using the Accessories

Vario Power Spray Wand

Adjusts cleaning pressure. Set to Max for high pressure, Min for low pressure/detergent.

Dirtblaster®

360° rotating 0° pencil jet for maximum dirt cutting action. Not for soft materials.

Care and Maintenance Instructions

Cleaning the Water Inlet Filter

Pull out the water inlet filter and rinse it clean.

Maintenance

Troubleshooting
