Kärcher KB 5 User Manual

8 English
During battery charging:
LED blinks green.
The battery is charged:
LED illuminates constantly in green.
LED lights up until the mains plug is re-
moved from the socket.
Operating mode:
LED illuminates constantly in green.
The battery must be charged:
The LED blinks slowly in red approx. 5
minutes before the battery has to be
charged.
Battery is empty:
LED illuminates constantly in red.
Motor blockade:
LED blinks red fast.
Put the device in the parking position
for at least 3 seconds (switch off de-
vice) for troubleshooting.
 The appliance is switched off, when
the handle is in an upright position.
 Switch on the appliance; press the
handle down.
 Move the appliance forward and
backward to clean.
LED indicator
OPERATING INSTRUCTIONS
Starting the work
OFF
ON

Kärcher KB 5 Specifications

General

Product type	Electric broom
Dust capacity	0.37 L
Product color	Black, Yellow
Dust container type	Bagless
Removable handheld vacuum	-
Number of brushes	1
Battery charger included	Yes
Power source	Battery
Battery voltage	3.7 V
Maximum input power	- W
Minimum runtime (carpet)	20 min
Minimum runtime (hard floor)	30 min
Cleaning type	Dry
Cleaning surfaces	Carpet, Hard floor
Working width (standard brush)	210 mm

Weight and Dimensions

Depth	215 mm
Width	230 mm
Height	1120 mm
Weight	1200 g
