Kärcher KM 100/100 R G User Manual

- 13
Technical specifications
KM 100/100 R G KM 100/100 R LPG
Machine data
Length x width x height mm 2006 x 1005 x 1343 2006 x 1005 x 1343
Unladen weight kg 300 300
Transport weight kg 375 375
Permissible overall weight kg 520 520
Driving speed km/h 8 8
Cleaning speed km/h 6 6
Climbing capability (max.) % 18 18
Roller brush diameter mm 285 285
Roller brush width mm 710 710
Side brush diameter mm 450 450
Working width without side brushes mm 710 710
Working width with 1 side brushes mm 1000 1000
Working width with 2 side brushes (option) mm 1290 1290
Volume of waste container l 100 100
Protection type, drip-proof -- IPX 3 IPX 3
Engine
Type -- Honda, 1 cyl., four-stroke Honda, 1 cyl., four-stroke
Cylinder capacity cm
3
270 270
Max. power kW/HP 6,6 / 9 6,6 / 9
Maximum torque at 2500 rpm Nm 19 19
Fuel type -- Petrol, unleaded Liquid gases (propellants): Butane and
propane or a mixture of butane/propane
RON 95 / EN 589
Tank content -- 6 l 11 kg / 20 litres (replacement cylinder)
Spark plug, NGK -- BPR 6 ES BPR 6 ES
Type of protection -- IP22 IP22
Battery
Type -- 12V, 44Ah 12V, 44Ah
Oil grades
Motor -- SAE 15W40 SAE 15W40
Sweeping hydraulics -- HVLP 46 HVLP 46
Axle drive -- SAE 10W-60 SAE 10W-60
Tyres
Size, front -- 4.00-4 4.00-4
Air pressure, front bar 6 6
Size, rear -- 4.00-8 4.00-8
Air pressure, rear bar 6 6
Brake
Service brake -- hydrostatic hydrostatic
Parking brake -- automatic (with spring) automatic (with spring)
Filter and vacuum system
Filter surface area, fine dust filter m
2
6,0 6,0
Category of use – filter for non-hazardous dust -- U U
Nominal vacuum, suction system mbar 12 12
Nominal volume flow, suction system l/s 50 50
Working conditions
Temperature °C -5...+40 -5...+40
Air humidity, non-condensing % 20 - 90 20 - 90
Values determined as per EN 60335-2-72
Noise emission
Sound pressure level L
pA
dB(A) 79 79
Uncertainty K
pA
dB(A) 2 2
29EN
