Kärcher NT 48/1 User Manual

– 2
1 Nameplate
2 Power cord
3 Holder for suction pipes
4 Holder for crevice nozzle
5 Drain hose
6 Suction hose
7 Suction head lock
8 Wheel
9 Dirt receptacle
10 Steering roller
11 Chassis handle
12 Floor nozzle
13 Suction tube
14 Suction support
15 Main switch
16 Suction head
17 Carrying handle
18 Cable hook
19 Bender
20 Cartridge filter
21 Fastening nut
22 Float
Caution
For dry vacuuming, the cartridge filter must
always be installed.
– To vacuum fine dust, you can also use
an additional paper filter bag.
Illustration
Illustration
 Release and remove the suction head.
 Insert the paper filter bag.
 Insert and lock the suction head.
Illustration
 Remove the brush strips.
 Install the rubber lips.
Note: The structured side of the rubber lips
must point outwards.
– To suck wet dirt, first remove the paper
filter bag.
 Release and remove the suction head.
 Turn the suction basket by 180° and
keep it aside.
 Loosen the mounting nuts
 Remove the cartridge filter.
Illustration
 Insert the fastening nut and tighten it.
 Install the additional filter.
 Insert and lock the suction head.
Illustration
The suction hose is equipped with a clip
system. All C-35/C-DN-35 accessories can
be connected.
 Plug in the main plug.
 Switch on the appliance at the main
switch.
– The vacuum channel is equipped with a
float.
– When the dirt water reaches the highest
permissible level in the container, the
suction power is interrupted.
 Switch off the appliance at the main
switch.
Illustration
 Empty the dirt container.
Drain off dirty water through the drain-
age hose.
Device elements
Start up
Dry vacuum cleaning
Inserting the paper filter bag
Wet vacuum cleaning
Inserting the rubber lips
Remove the paper filter bag
Installing an additional filter
Clip connection
Operation
Turning on the Appliance
Emptying the dirt container
8 EN

Kärcher NT 48/1 Specifications

General

Standard nominal width	35 mm
Dust capacity	48 L
Container material	Plastic
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	1380 W
Airflow	67 l/s
Noise level	72 dB

Weight and Dimensions

Depth	390 mm
Width	490 mm
Height	780 mm
Weight	10500 g
