Kärcher SC 3 EasyFix User Manual

English 9
1 Decalcification cartridge
2 Filling hole for water
3 Carrying handle
4 Holder for accessories
5 Display
6 Indicator light (green) - mains volt-
age present
7 Indicator light (red) - water shortage
8 Indicator light (red) - replace decal-
cification cartridge
9 RESET button - set water hardness
10 Switch - On
11 Switch - Off
12 Park bracket for floor nozzle
13 Mains connection cable with mains
plug
14 Non-driven wheels (2 x)
15 Steering roller
16 Steam gun
17 Steam lever
18 Unlocking button
19 Selector switch for steam volume
(child lock)
20 Steam hose
21 Spotlight nozzle
22 Round brush (small, black)
23 Manual nozzle
24 Microfiber cover for manual nozzle
25 Extension tubes (2 x)
26 Unlocking button
27 Floor nozzle
28 Hook and loop fastener
29 Microfiber floor cloth (1 x)
Initial commissioning
ATTENTION
Device damage due to calcification
The decalcification cartridge only
works properly if you adjust the device
to the local water hardness before op-
erating it for the first time.
Set the device to the local water hard-
ness.
Set the device to the current water
hardness before using it in an area with
a different water hardness (e.g. after a
move)
1. Insert the decalcification cartridg
e
into the opening and push it so that
it is firmly in place.
2. Set the water hardness, see chapter
Setting the water hardness.

Kärcher SC 3 EasyFix Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Type	Cylinder steam cleaner
Capacity	1 L
Hose length	2 m
Product color	Black, Yellow
International Protection (IP) code	IPX4
Ready time	0.5 min
Steam pressure	3.5 bar
Adjustable steam	Yes
Cleaning surfaces	Glass, Hard floor, Tiles
Continuous steam performance	40 g/min

Weight and Dimensions

Depth	360 mm
Width	236 mm
Height	253 mm
Weight	3100 g
