Kärcher SC 3 User Manual

10 English
ATTENTION
In order to guarantee the optimum function-
ality of the descaler cartridge, the device
must be set to the local water hardness pri-
or to the first operation.
This is done via the RESET button.
Notes
 The device is set to the highest water
hardness level (level IV) by default.
 After completion of the water hardness
setting, it remains saved until a new set-
ting (e.g. after relocation) is necessary.
 During the setting no pause of more
than 15 seconds may take place. Other-
wise the device is automatically set to
the water hardness selected last or the
highest water hardness with initial start-
up.
Please observe the following procedure:
 Connect the mains cable to the power
supply system.
 The device must be switched off prior to
the setting.
 Push the RESET button and hold it
down during the start-up of the device.
 After 2 seconds the indicator light is
blinking and signals the current setting
of the water hardness via the number of
impulses.
 By repeatedly pressing the RESET but-
ton, the setting of the water hardness
level changes.
 As long as the RESET button is
pressed, the flashing impulse for the
relevant water hardness level is not
shown.
 As soon as the button is released, the
flashing impulse appears for the output
of the selected water hardness.
 If the water hardness is set to the de-
sired level, hold down the RESET but-
ton for 3 seconds so that the setting is
saved.
 The saving process is displayed by the
lighting up of the indicator light for the
water hardness.
ATTENTION
If the device is used in another area with a
different water hardness (e.g. after reloca-
tion), the water hardness must be reset.
 Illustrations on fold-out
page 3!
Illustration
 Insert steering roller and runningwheels
and lock them.
Illustration
Illustration
 Connect the required accessories (see
Chapter "How to use the accessories“)
to the steam gun. Insert the open end of
the accessory on the steam gun and
push onto the steam gun until the un-
locking button of the steam gun locks
into place.
Illustration
 Use the extension tubes if necessary.
To do so, connect one or both exten-
sion tubes to the steam gun. Insert the
required accessories on the free end of
the extension tube.
 Move the selector switch for the steam
volume back (steam lever locked).
Illustration
 To detach the accessory parts, press
the unlocking button and pull the items
apart.
Setting of the water hardness
Operation
Assemble the appliance
Removing the Accessories

Kärcher SC 3 Specifications

General

Type	Cylinder steam cleaner
Capacity	1 L
Cord length	4 m
Hose length	2 m
Product color	Black, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Steam pressure	3.5 bar
Continuous steam performance	40 g/min
On/off switch	Yes

Weight and Dimensions

Depth	360 mm
Width	236 mm
Height	253 mm
Weight	3.14 g
