Steam
CAUTION - Danger of scalding
Illustration
1 Safety lock (steam boiler)
2 Operating field
3 Steam hose
4 Reset key - Descaling
5 Steam switch
6 Accessory compartment
7 Cover of the appliance connector
8 Steam plug
9 Carrying handle
10 Cable hook
11 Hood
12 Container closure (fresh water tank)
13 Terry cloth cover
14 Funnel inlet
15 Hand nozzle
16 Window nozzle (option)
17 Power cord
18 Retaining clip
19 Floor nozzle with bristles
20 Floor cleaning cloth (floor nozzle with
bristles)
21 Round brush
22 Power nozzle (red)
23 Extension piece
24 Floor nozzle with lamellae
25 Detail nozzle (4.7 in/120 mm)
26 Detail nozzle (7.1 in/180 mm)
27 Floor cleaning cloth (floor nozzle with
lamellae)
28 Locking knob
29 Extension tube
30 Lock (child-proof lock)
31 Steam gun
Illustration
1 Switch - pump fresh water tank
2 Indicator lamp - heating (yellow)
3 Indicator lamp - water shortage steam
boiler (red)
4 Temperature display
5 Rotary knob for VAPOHYDRO regula-
tion
6 Rotary knob for steam quantity control-
ler
7 Working temperature range
8 Indicator lamp - Descaling (white)
9 Indicator light - water shortage fresh
water tank (red)
10 Switch - heating (ON/OFF)
– The operating elements for the cleaning
process are yellow.
– The controls for the maintenance and
service are light gray.
Safety devices serve for the protection of
the user and must not be put out of opera-
tion or bypassed with respect to their func-
tion.
The pressure controller keeps the boiler
pressure during the operation as constant
as possible. The heating is turned off if the
maximum operating pressure of 4 bar is
reached in the boiler and is reactivated in
case of a pressure drop in the boiler due to
steam tapping.
When the water in the boiler becomes ex-
hausted, the temperature of the heating in-
creases. The low-water thermostat turns off
the heating, and the red low-water indicator
lamp "water shortage" lights up. The heat-
ing is prevented from being turned on again
until the boiler has cooled down or been re-
filled with water.
Symbols on the machine
Risk of burns on account of hot
surfaces!
Overview
Device elements
Operating field
Colour coding
Safety Devices
Pressure controller
Water shortage thermostat
8 EN

Kärcher SG 4/4 Specifications

General

Type	Cylinder steam cleaner
Capacity	4 L
Cord length	7.5 m
Control type	Buttons, Rotary
Product color	Black, Grey, Yellow
Number of water tanks	2
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Steam pressure	4 bar
Adjustable steam	Yes
Steam adjustment type	Stepless
Number of accessories included	10 pc(s)

Weight and Dimensions

Depth	475 mm
Width	320 mm
Height	275 mm
Weight	8000 g
Package weight	11200 g
