Kärcher SGV 6/5 User Manual

– 12
Technical specifications
SGV 6/5 SGV 8/5
Mains voltage V 120 120
Frequency Hz 1~ 60 1~ 60
Voltage in the handle V 5 5
Nominal power of the appliance (total) W 1600 1600
Nominal power fan W 1200 1200
Rated input boiler W 1600 1600
Main pump W 52 52
Water pump W 27 27
Steam boiler gal (l) 0.9 (3.4) 0.9 (3.4)
Filling quantity fresh water container gal (l) 1.5 (5.6) 1.5 (5.6)
Filling quantity wastewater container gal (l) 1.3 (5.0) 1.3 (5.0)
Filling quantity detergent container gal (l) -- 0.5 (2.0)
Air volume (max.) CFM (l/s) 150 (71) 150 (71)
Negative pressure (max.) mm (kPa) 2590 (254) 2590 (254)
Working pressure psi (MPa) 87 (0.6) 116 (0.8)
Steam pressure (max.) psi (MPa) 145 (1.0) 174 (1.2)
Steam quantity (max.) - consistent oz/min
(g/min)
1.9 (55) 1.9 (55)
Heating time min 12.0 13.5
Max. operating temperature of hot water °F (°C) 158 (70) 158 (70)
Max. operating temperature of steam °F (°C) 327 (164) 343 (173)
Water flow rate gal/min
(l/min)
0.16 (0.6) 0.16 (0.6)
Detergent flow rate gal/min
(l/min)
-- 0.18 (0.7)
Type of protection -- IPX4 IPX4
Protective class -- I I
Length x width x height in (mm) 22.2 x 19.5 x 38.0
(640 x 495 x 965)
22.2 x 19.5 x 38.0
(640 x 495 x 965)
Typical operating weight lbs (kg) 85 (39) 88 (40)
Angle of inclination (max.) ° 10 10
Values determined as per EN 60335-2-68
Sound pressure level L
pA
dB(A) 67 67
Uncertainty K
pA
dB(A) 1 1
Power cord SJOW 3/14 AWG
Part no.: Cable length
CUL 6.650-477.0 7.5 m
21EN
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

Kärcher SGV 6/5 Specifications

General

Brand	Kärcher
Model	SGV 6/5
Category	Vacuum Cleaner
Language	English
