GB - 16
3.5 Control board Compact/General/Application without encoder interface
3.5.1 X2A Control Terminal Strip
Tightening torque 0.22…0.25 Nm (2 lb inches) X2A
Use shielded/drilled cables
123456789
10 11 12 13 14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 29
Lay shield on one side of the inverter onto earth
potential
PIN Function Name Description
Differential voltage input 0…±10 V DC; Ri = 55 kΩ
1 + Setpoint input 1 AN1+
Setting of the analog setpoint
2 - Setpoint input 1 AN1-
3 +Analog input 2 AN2+
At factory setting no function
4 -Analog input 2 AN2-
Programmable analog outputs 0…±10 V DC (max. 5 mA)
5 Analog output 1 AO1 Output frequency 0…±100 Hz
6 Analog output 2 AO2 Apparent current 0…2•I
N
7 +10V output CRF Reference voltage for setpoint poti
+10 V DC / max. 4 mA
8
Analog ground COM Ground for analog in- and output
9
Programmable digital inputs 13…30 V DC ±0 % smoothed Ri: 2.1 kΩ; scan time: 2 ms
10 Fixed frequency 1
(CP.19)
I1 Selection of xed frequency
I1 + I2 = xed frequency 3 (CP.21)
11 Fixed frequency 2
(CP.20)
I2
12 External fault I3 Input for external error setting (E.EF)
13 DC braking I4 Activates DC braking (CP.22/23)
14 Forward F Rotation selection
15 Reverse R Forward has priority
16 Control release / Reset ST Power modules are enabled; reset at opening
17 Reset RST Reset; only when an error occurs
Digital outputs I = max. 50 mA
18 Transistor output 1 O1 Switched at real value = setpoint value
19 Transistor output 2 O2 Ready signal - switched as long as no error occurs
20 24 V - output Uout Supply of the digital inputs (24 V DC/ max. 100 mA)
21 20…30 V - input Uin Voltage input for external supply
22
Digital ground 0V Reference potential for digital inputs/outputs
23
Relay outputs Load capacity max. 30 V DC / 0.01…1 A
24 Relay 1 / NO contact RLA
Programmable relay output (CP.31)
Factory setting: Fault relay
25 Relay1 / NC contact RLB
26 Relay1 / switching
contact
RLC
27 Relay 2 / NO contact FLA
Programmable relay output (CP.32)
Factory setting: Frequency denpendent switch
28 Relay 2 / NC contact FLB
29 Relay 2 / switching
contact
FLC
