28
29
CARE AND CLEANING
1. Water Dispenser
Remove the strainer and clean the water collecting
tray with a sponge or absorbent cloth.
2. Ice Storage Bin
Removing: Press the release button and remove the
ice cube bin.
Cleaning: Empty the ice cube bin and clean with
lukewarm water.
Thoroughly dry the bin and screw conveyor to
prevent new ice cubes from sticking.
Replacing: Push the ice cube bin all the way back
onto the supports until it locks into position.
If the bin cannot be pushed all the way back, rotate
the ice auger a quarter turn and insert again.
3. Freezer & Refrigerator Bins
Hold both ends and pull up.
4. Refrigerator Shelves
Lift up and pull the shelf, unhook and then remove
the shelf. You can replace it at varying heights.
To place taller items such as bottles, you can you
can remove the small glass shelf and place
it in the holder under the icemaker.
Be sure to
unplug rst
* Features may vary according to model.
F706-4(영)(Kenmore)_신포맷.indd 29 2016-08-29 오후 3:36:57
