23
Care and Cleaning
Replacing the oven light
Be sure the oven is unplugged and all parts are
cool before replacing oven light.
The interior oven lights are located at the rear of the oven cavity
and are covered with a glass shield. The glass shield must be in
place whenever the oven is in use (See Figure 25).
To replace the oven interior light bulb:
Important note:
Do not allow your fingers to touch the new bulb when replacing.
This will shorten the life of the bulb. Use a paper towel or cotton
glove while handling the new bulb when installing.
1. Turn electrical power off at the main source.
1. Remove interior oven light shield by turning a quarter turn
counter-clockwise.
2. Replace bulb with a new T-4 type Halogen 25 watt
appliance bulb.
3. Replace glass oven light shield by rotating clockwise.
4. Turn power back on again at the main source .
5. Be sure to reset the time of day on the clock.
Figure 25: Wall oven Halogen light
