Need help?Do you have a question about the Kenwood DMF-3020 and is the answer not in the manual?
Digital Audio Performance| frequency response (playback mode) | 8 Hz ~ 20 kHz (± 1 dB) |
|---|---|
| signal to noise ratio (playback mode) | More than 105 dB |
| dynamic range (playback mode) | More than 94 dB |
| total harmonic distortion (1 kHz, playback mode) | Less than 0.007 % |
| analog input sensitivity / input impedance | 500 mV / 22 kΩ or more |
| analog output level / output impedance | 2.0 V / Less than 400 Ω |
| headphone output | 20 mW/32 Ω load |
| digital input (coxaial) | 0.5 Vp-p / 75 Ω |
| digital input (optical) | Wave length 660 nm, - 15 dBm ~ - 21 dBm |
| digital output (coxaial) | 0.5 Vp-p / 75 Ω |
| digital output (optical) | Wave length 660 nm, - 15 dBm ~ - 21 dBm |
General Specifications| power consumption | 18 W |
|---|---|
| dimensions (W x H x D) | 440 mm x 94 mm x 379 mm |
| weight | 4.0 kg |
Digital Audio Performance| frequency response (playback mode) | 8 Hz ~ 20 kHz (± 1 dB) |
|---|---|
| signal to noise ratio (playback mode) | More than 100 dB |
| dynamic range (playback mode) | More than 90 dB |
| total harmonic distortion (1 kHz, playback mode) | Less than 0.01 % |
| analog input sensitivity / input impedance | 500 mV / 22 kΩ or more |
| analog output level / output impedance | 2.0 V / Less than 400 Ω |
| headphone output | 20 mW/32 Ω load |
| digital input (coxaial) | 0.5 Vp-p / 75 Ω |
| digital input (optical) | Wave length 660 nm, - 15 dBm ~ - 21 dBm |
| digital output (coxaial) | 0.5 Vp-p / 75 Ω |
| digital output (optical) | Wave length 660 nm, - 15 dBm ~ - 21 dBm |
General Specifications| power consumption | 18 W |
|---|---|
| dimensions (W x H x D) | 440 mm x 94 mm x 379 mm |
| weight | 4.0 kg |
