KIA DELIVERY FIRST
–
THE PRIORITY THAT DELIVERS MORE
5
Always check the Owner’s Manual for complete operating information and safety warnings.
* If equipped.
A
Tachometer: The tachometer indicates number of engine revolutions per minute.
B
Engine Temperature Gauge: This gauge shows the temperature of the engine coolant. If the needle
nears the “H” position on the gauge, it indicates
an overheating engine. Do not drive your
vehicle in this condition.
C
Turn Signal Indicators: The indicators
will illuminate when the turn signal
control is engaged.
D
Shift Pattern Indicator:
Indicates shift lever selection.
(Automatic Transaxle only).
E
Odometer: The odometer indicates the
total distance the vehicle has been driven.
F
Speedometer: Indicates speed of vehicle.
G
Fuel Gauge: Displays approximate amount of fuel
remaining in the vehicle.
H
Tripmeter: The tripmeter can record individual trip
distances for up to two different trips (A or B). The
tripmeter button (located to the left of the steering
wheel column) will reset the meter to “0” if pressed
longer than one second.
1
C
H
E
F
0
2
20
40
60
80
100
120
140
0
3
4
5
x1000 rpm
km/h
0
20
40
60
80
100
120
140
160
180
200
220
MPH
6
7
8
INSTRUMENT CLUSTER
F
E
A
B
DC
G
H
C
H
