Features of your vehicle
1563
Rear mode selection (if equipped)
When the rear climate control selection
(REAR CONTROL) button in the front cli-
mate control panel is in the OFF position
or the button is not equipped, the rear
mode is controlled automatically depend-
ing on the mode of the front climate con-
trol as follows:
• Front climate control is MAX A/C,
:
Rear air blows from the upper vents on
the rear ceiling.
• Front climate control is :
Rear air blows from the upper vents on
the rear ceiling and the lower vents on
the right rear trim together.
• Front climate control is , , :
Rear air blows from the lower vents on
the right rear trim.
❇ If the rear air conditioner is not
equipped, rear air blows only from the
lower vents.
❇ If the rear heater is not equipped, rear
air blows only from the upper vents.
When the rear climate control selection
(REAR CONTROL) button in the front cli-
mate control panel is in the ON position,
the rear mode is selected by pushing the
rear mode selection button on the rear
control panel as follows:
• : Rear air blows from the upper
vents on the rear ceiling.
• : Rear air blows from the upper
vents on the rear ceiling and the
lower vents on the right rear trim
together.
• : Rear air blows from the lower
vents on the right rear trim.
OVQ028338
1VQA2174
with rear air conditioner
with rear heater
OVQ049317
