DESCRIPTION OF OPERATING SYSTEM
4
TACHOMETER/HOUR METER
INDICATOR
(1) Tachometer
(2) Hour Meter Indicator
(3) Rated Engine Speed
(1) Fuel Gauge
“E” : Empty “F” : Full
FUEL GAUGE
This indicates the remaining fuel
level after the key switch is turned to
the “ON” position.
• F:Fuelisfullylled.
• E : Replenish the fuel tank.
If driving is continued with the needle
below the position “E”, air may enter
the fuel supply system. In this case,
“bleed” the system. (For detailed
instructions, refer to “Bleeding fuel
system” in the chapter “Service”)
It indicates the engine rpm that can
drive 540 rpm of P.T.O speed. For
speedy and effective work, adjust the
work load so that the engine rpm is
close to this mark "
▲
".
The hour meter does not operate if
the engine is stopped even though
the key switch is in the "ON" position.

Make sure to use only correct
fuel as the engine can be dam-
agedifunqualiedfuelisused.

Use fuel for winter season in
cold weather to start the engine
easier.

The gauge needle can move on
a hill or curve as fuel slopes in
the tank.
NOTE
111
22
33
tb3O402A
111
tb3O403A
CS2220H(S),CS2520H(S)-미국향-04.ind11 11 2020-03-31 오후 4:23:25
